3590ET - 3590EGT
Serial commands
TECHNICAL MANUAL
ENGLISH
www.diniargeo.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3590ET and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dini Argeo 3590ET

Summary of Contents for Dini Argeo 3590ET

  • Page 1 3590ET - 3590EGT Serial commands TECHNICAL MANUAL ENGLISH www.diniargeo.com...

  • Page 3: Table Of Contents

    1. Format of the serial commands 2. 485 Communication 3. Scale instrument answers 4. Commands divided by argument 1.1 Weight reading commands 1.2 Weight setting commands 1.3 Scales commands 1.4 Power commands 1.5 Alibi memory commands 1.6 Analog output command 1.7 Keys related commands 1.8 Display commands 1.9 Audio buzzer commands...
  • Page 4 FREZ GETI GINR GKBB GR10 GREC IALA INPU INUN KEYE KEYP KEYR LNKF MVOL NREC NTGS OUTP PAPER PRNT RALL RAZF READ REXT RREC RUBU SPMU SREC STAT STPD STPT TARE TMAN TOPR WREC...
  • Page 5 WUBU ZERO 6. Simple example...

  • Page 6: Format Of The Serial Commands

    Serial ports → Pc port configuration → CTS status Select the CTS status Standard Serial ports → Pc port configuration → Protocol Extended For alibi memory Serial ports → Pc port configuration → Communication mode On demand 3590ET - 3590EGT_Serial_Commands...

  • Page 7: Communication

    Command format wrong <CR> <LF> Command parameters error <CR> <LF> Command not allowed in the scale state <CR> <LF> Unrecognized command <CR> <LF> Internal factory use <CR> <LF> Internal factory use <CR> <LF> Password protected (related to BASIC application) 3590ET - 3590EGT_Serial_Commands...

  • Page 8: Commands Divided By Argument

    Switches the main weight display value from gross to net and vice versa Change the weighing channel RAZF Get the ADC value of the selected instrument channel Reading of the instrument serial number STAT Reading of the instrument working state Reading of the instrument model and firmware version 3590ET - 3590EGT_Serial_Commands...

  • Page 9: Power Commands

    Set the instrument scale in the alphanumerical input state INUN Set the instrument scale in the numeric input state Reading of the last data inserted by the user after the execution RUBU of the IALA command WUBU Writes data in the user buffer 3590ET - 3590EGT_Serial_Commands...

  • Page 10: Audio Buzzer Commands

    Reading of the number of occupied records and the total number NREC of records of a database RREC Reading of a record of a database SREC Selects a record of a database WREC Writing of a record of a database 3590ET - 3590EGT_Serial_Commands...

  • Page 11: Commands In Alphabetical Order

    Power supply x...x ≥ 0 connection 1: power supply voltage in millivolt connected 0 - 9 Battery voltage y...y Battery value 0: discharged ≥ 0 in millivolt 9: charged Command Example 1 Answer Command Example 2 Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 12: Alrd

    Tare value (decimal value with decimal point on 10 characters padded on front with blanks). Command Example Answer ANOU Description Analog output value setting. Note Allowed in technical setup only Format Where xxxx DAC value in hex format (0h to FFFFh). Answer Command Example Answer 3590ET - 3590EGT_Serial_Commands...
  • Page 13 Description Enable / Disable the automatic transmission of the pressed keys. Note Works on EGT-AF01 only. е Format е 0 disable Where 1 enable Answer Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 14: Baud

    2 seconds of communication silence. Baud rate index. Value Baud rate [bps] Where 9600 19200 38400 57600 115200 Answer Temporarily set 19200 as pc serial port baud rate. Example Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 15: Beep

    369.68 Where 391.84 SOL# 414.96 440.00 465.92 493.84 Anglo-Saxon German ddddd Duration time of the acoustic sound in milliseconds expressed as decimal value. Value 00000 turns the buzzer off. Answer 1 second FA/F note. Example Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 16: Bridge

    Serial port connected to the PC serial port Value Description Where PC port connected to AUX port PC port connected to printer port Answer Connects the printer serial port with the PC serial port. Example Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 17: Cgch

    Change the weighing channel. Format Where Channel number (decimal value, 0 switches to the remote scale). Answer Switches to the scale channel 2. Example Command Answer CLEAR Description Simulates the pressure of the CLEAR key. Format Answer Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 18: Cmdoff

    Turns the indicator off. Format Answer Command Example Answer CMDRESET Description Restarts the indicator. Format Answer Command Example Answer CMDSAVE Description Save the setup parameter. Note Works in the setup environment only. Format Answer Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 19: Cmdsetup

    CMDSETUP Description Enter in the setup environment. Note Command accepted in the BOOT_START state only. Format Answer Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 20: Dint

    The message is displayed for the interval time set with the DINT command. During the visualization of the message, the customizable area is locked. Format Where c...c Message to display. Answer Displays the message “GOOD MORNING” on the system message area. Example Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 21: Echo

    Eco of the received characters. Note Works on EGT-AF01 only. Format Where c...c Arbitrary characters. Answer Where c...c Same characters of the received command. Command Example Answer EKBB Description Clear the keyboard buffer. Format Answer Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 22: Exit

    EXIT Description Simulates the pressure of the OK key. Format Answer This command has no answer. Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 23: Frez

    FREZ Description Stores the present data weights in the scale frozen data area. Note Doesn’t work on EGT-AF04. Format Answer Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 24: Geti

    Get the numeric value inserted by the user. Note Use the INUN (pag. 29) command to set the numeric input state. Format Answer Where d...d Numeric value inserted by the user in decimal format without decimal point. Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 25: Gkbb

    8/F8 touch el. touch el. toolbar el. 9/F9 touch el. touch el. toolbar el. ZERO/. touch el. touch el. toolbar el. touch el. touch el. OK/>> touch el. touch el. Table 1. Key codes 3590ET - 3590EGT_Serial_Commands...

  • Page 26: Gr10

    Unit of measure (“g”, “kg”, “t”, “lb”). Enables compatibility mode. Example 1 Command Answer Weight in high resolution with compatibility mode disabled. Example 2 Command Answer Weight in high resolution with compatibility mode enabled. Example 3 Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 27: Grec

    Database index. Where rrrr Selected record index. NULL if the database hasn’t a selected record. Reading of the selected record of the database 2 when the index of the selected record is equal 1. Example Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 28: Iala

    0001 Input n activated and so on Reading of the digital input 1 status when it is activated. Example 1 Command Answer Reading of all digital inputs status with inputs 2 and 8 activated. Example 2 Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 29: Inun

    Upper bound value the user can insert Where i…i Initial value displayed Input size in digits Number of decimals Answer Insertion of a value between 0.00 and 100.00 with 2 decimals with 50.0 as initial value. Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 30: Keye

    Key code in hexadecimal format (see Table 1 at pag. 25 for the key codes). Answer Simulation of the pressure of the ZERO key. Example 1 Command Answer Simulation of the pressure of the 1st toolbar button. Example 2 Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 31: Keyr

    KEYR Description Simulation of the release of the key. Format Answer Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 32: Lnkf

    02.00. Format Print function index (1 ÷ instrument available print functions). Where Print format index (0 ÷ instrument available print formats). Answer Sets the print format of the print function 5 equal to 10. Example Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 33: Mvol

    Channel voltage value equal to 5145 μV in independent channels working mode. Example 1 Command Answer Reading of the 2 configured channels voltages in dependent channels working mode, channel voltage = 1000 μV, 2 channel voltage = 2000 μV. Command Example 2 Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 34: Nrec

    Total number of records of the database. Database 1 has 500 records with 100 of them occupied. Example Command Answer NTGS Description Switches the main weight display value from gross to net and vice versa. Format Answer Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 35: Outp

    Output to be deactivated. Answer Activate the digital output 2. Example 1 Command Answer Deactivate the output index 4. Example 2 Command Answer Activate outputs 1 and 5 and deactivate the remaining ones. Example 3 Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 36: Paper

    Reading of paper status of the connected printer with paper sensor. Description Note: Available just in the AF03 software version. Format No answer from the printer. Paper ok. Answers Paper low. Out of paper. Command Example Answer 3590ET - 3590EGT_Serial_Commands...
  • Page 37 In case of error with no weight data stored in alibi memory in place of rrrrr-nnnnnn there is Data stored in alibi with a gross weight equal to 15 kg and a preset tare of 1 kg when the instrument is on channel 1. Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 38: Prnt

    Where Print function index (0 ÷ instrument available print functions - 1). Print format index (0 ÷ instrument available print formats). Answer Sets the print format of the print function 5 equal to 10. Example Command Answer 3590ET - 3590EGT_Serial_Commands...
  • Page 39 Description Change the weighing channel. Format Where Channel number (decimal value, 0 switches to the remote scale). Answer No answer. Switches to the scale channel 2. Example Command Answer 3590ET - 3590EGT_Serial_Commands...
  • Page 40 Tare value padded with blank spaces on front. Standard protocol with a net weight of 2.000kg. Example 1 Command Answer Extended protocol with a preset tare of 1.000kg and a gross weight of 2.000kg read from scale channel 1. Command Example 2 Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 41: Rall

    (*) Every pressed key is stored in an internal instrument buffer. Every time the RALL command is executed a key is retrieved from the buffer following the last in first out rule, this way the keys are retrieved in the reverse order they were pressed. 3590ET - 3590EGT_Serial_Commands...

  • Page 42: Razf

    ADC voltage value equal to 450000 in independent channels working mode. Example 1 Command Answer Reading of the 2 configured channels ADC values in dependent channels working mode, 1 channel ADC value = 15000, 2 channel ADC value = 20000 Command Example 2 Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 43: Read

    Tare value padded with blank spaces on front. Standard protocol with a net weight of 2.000kg. Example 1 Command Answer Extended protocol with a preset tare of 1.000kg and a gross weight of 2.000kg read from scale channel 1. Command Example 2 Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 44: Rext

    Average piece weight (EGT AF02) on 10 characters with 5 decimals padded with blank spaces on front. Unit of measure (“g”, “kg”, “t”, “lb”). Standard protocol with a net weight of 2.000kg. Command Example 1 Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 45: Rrec

    The sum of the ASCII values in hexadecimal is 630. The sum modulo 256 in hexadecimal is 30. In the answer string the checksum value is splitted on 2 characters: the character ‘3’ and the character ‘0’. 3590ET - 3590EGT_Serial_Commands...

  • Page 46: Rubu

    RUBU Description Reading of the last data inserted by the user after the execution of the IALA command. Note See pag. 28 for IALA command. Format Answer Where c...c Data inserted by the user. Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 47: Spmu

    Database index (0÷instruments available databases – 1). rrrr Record index (0÷database total number of records – 1), set 9999 to deselect the database record. Answer Where Database index. rrrr Record index. Selects the record 1 of the database 2. Example Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 48: Stat

    Reception / transmission of setup Serial test Print test Dosage Stand-by User input Auto zero Diagnostic Digital output diagnostic Table 2. Instrument states STPD This command is the same as STPT (pag. 49) with STPD in place of STPT. 3590ET - 3590EGT_Serial_Commands...

  • Page 49: Stpt

    NOTE: if the setpoint hysteresis is disabled the off value is ignored but must be less than the on value. Answer Sets the on value of the 2 setpoint equal to 2.000 kg and the off value equal to 1.900 kg in a scale calibrated with 3 decimals Example Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 50: Tare

    Tare to set with decimal point on up to 8 characters. Answer Sets a preset tare equal to 1.5 kg. Example 1 Command Answer Sets a preset tare equal to 10 kg. Example 2 Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 51: Topr

    Characters to send to the printer port. To send non printable characts (i.e. CR) use \ddd where ddd is the decimal value of the character. Answer Sends to the printer “LINE 1<CR><LF>LINE 2<CR><LF>” Command Example Answer 3590ET - 3590EGT_Serial_Commands...
  • Page 52 Description Reading of the instrument model and firmware version. Format Answer Where r [r] Firmware major release in decimal value. Firmware minor release. m...m Model name on 8 characters. EGT-AF01 release 1.00 connected. Example Command Answer 3590ET - 3590EGT_Serial_Commands...
  • Page 53 Tare to set with decimal point on up to 8 characters. Answer No answer. Sets a preset tare equal to 1.5 kg. Example 1 Command Answer Sets a preset tare equal to 10 kg. Example 2 Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 54: Wrec

    Allows to set the data that will be displayed when the IALA (pag. 28) command is executed with the initial Note value display enabled. Format Where c...c Characters to insert in the user buffer. Answer Insert the string “AB123” in the user buffer Example Command Answer 3590ET - 3590EGT_Serial_Commands...
  • Page 55 Sets the average piece weight in the set AVG unit. Note Works on EGT-AF02 only. Format Where x...x Average piece weight value with decimal point on up to 8 characters. Answer No answer. Sets an average piece value equal to 10.5. Example Command Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 56: Zero

    Description Zero scale function. Format Answer No answer. Command Example Answer ZERO Description Zero scale function. Format Answer Command Example Answer 3590ET - 3590EGT_Serial_Commands...

  • Page 57: Simple Example

    Console.WriteLine(ex.Message); return; string Command = “READ\r\n”; //command to send string Rx; //reception string //regular expression related to the READ command answer (ss,wtwt,wwwwwwww,uu) Regex regexp = new Regex(“^[A-Z]{2}\\,[A-Z]{2}\\,[\\x20]*(?<weight>\\-?[0-9]+(\\.[0-9]+)?)\\,” + “(?<um>[a-z]{2})\\r\\n$”); Console.WriteLine(“Press Q to quit”); //main loop while (true) 3590ET - 3590EGT_Serial_Commands...
  • Page 58 (elapsed.TotalSeconds > 1.0) //timeout elapsed: quit from reception cycle Console.WriteLine(“-----”); break; System.Threading.Thread.Sleep(10); //wait 10 ms to allow other data to be received } //reception cycle end } //main loop end port.Close(); //serial port closing The console output is displayed in Figure 1. 3590ET - 3590EGT_Serial_Commands...
  • Page 59 3590ET - 3590EGT_Serial_Commands...
  • Page 60 NOTES 3590ET - 3590EGT_Serial_Commands...
  • Page 61 NOTES 3590ET - 3590EGT_Serial_Commands...
  • Page 62 NOTES...
  • Page 64 Timbro centro assistenza autorizzato HEAD OFFICE Via Della Fisica, 20 41042 Spezzano di Fiorano, Modena - Italy Tel. +39.0536 843418 - Fax. +39.0536 843521 info@diniargeo.com SERVICE ASSISTANCE Via Dell’Elettronica, 15 41042 Spezzano di Fiorano, Modena - Italy Tel. +39.0536 921784 - Fax. +39.0536 926654 service@diniargeo.com...
