WEIGHT INDICATOR
TECHNICAL MANUAL
E-AF03: IN/OUT WEIGHING WITH
CUSTOMER/PRODUCT/VEHICLES DATABASE
3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET
series indicator
E-AF03_05.01_14.07_EN_T

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3590EKR Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dini Argeo 3590EKR Series

Summary of Contents for Dini Argeo 3590EKR Series

  • Page 1 WEIGHT INDICATOR TECHNICAL MANUAL E-AF03: IN/OUT WEIGHING WITH CUSTOMER/PRODUCT/VEHICLES DATABASE 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T...

  • Page 2: Table Of Contents

    1.2 EARTHING SYSTEM ..................................6 2. CONNECTION TO THE LOAD RECEIVER ............................9 2.1 ANOLOG LOAD CELLS ................................9 CONNECTION TO STANDARD “DINI ARGEO” FEMALE CONNECTOR ..................10 2.2 DIGITAL LOAD CELLS ................................10 2.3 CONNECTION OF LOAD CELLS TO INDICATOR ........................11 2.3.1 C16i DIGITAL CELL CONNECTION ..........................
  • Page 3 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 9.2.2 CODE PAGE 1251 WINDOWS CYRILLIC ........................104 9.2.3 CODE PAGE 1253 WINDOWS GREEK ........................105 9.3 LIST OF PRINT BLOCKS ................................106 9.3.1 ORDER BY KIND ................................106 9.3.2 NUMERICAL ORDER ..............................113 9.4 BLOCKS WITH PARAMETERS ..............................

  • Page 4: Requirements For An Optimal Installation

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 1. REQUIREMENTS FOR AN OPTIMAL INSTALLATION To obtain the best results it is recommended to install the indicator and the platform (or transducer) in a place with the following conditions: A flat, level surface on which to rest Stable and vibration free No dust or strong vapours...

  • Page 5: Cable Classification

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 1.1.1 CABLE CLASSIFICATION The various cables are classified depending on the transmitted signals: Category I - Field bus, LAN (PROFIBUS, Ethernet, Devicenet…) - Shielded data cables (RS232 …) - Shielded cables for analogue/digital signals < 25V (sensors, load cells…) - Low tension power supply cables (<...

  • Page 6: Earthing System

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc ANALOG OUTPUT CABLE The maximum length of the analogue output cable in current is: - 100 m with cable 2 x 0,25 mm - 150 m with cable 2 x 0,5 mm - 300 m with cable 2 x 1 mm The maximum length of the analogue output cable in voltage is: - 50 m with cable 2 x 0,25 mm...
  • Page 7 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc GENERAL NOTES:  All the grounding cables must have an adequate length, in order to obtain an overall resistance of grounding system less than 1 Ω.  In the case the weighing system regards great and/or outdoor structures, like weighbridges: - The grounding connection is to be made by connecting the grounding cables to a grounding bar and the grounding bar to the grounding pole with a cable section not less than 50 mm2.
  • Page 8 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc EARTHING EXAMPLE OF A SILO Non weighing structure (silo) U-bolt between plate under cell Weighing and weighing structure structure (not supplied) Load cell Ø 4,6 – 16 mm² earth cable section (not supplied) Ø...

  • Page 9: Connection To The Load Receiver

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 2. CONNECTION TO THE LOAD RECEIVER 2.1 ANOLOG LOAD CELLS IMPORTANT: Respect the electrical precautionary measures indicated in section 1. After having followed the instructions regarding the platform or the load receiver, the screened cable leading from the load cell(s) must be connected to the instrument through the CELL1 terminal board and the CELL1, CELL2, CELL3, CELL4 connectors;...

  • Page 10: Connection To Standard "Dini Argeo" Female Connector

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc CONNECTION TO STANDARD “DINI ARGEO” FEMALE CONNECTOR 1 EXCITATION + 2 EXCITATION – 3 SENSE - 4 SENSE + 5 SIGNAL - 6 SIGNAL + 7 NOT CONNECTED 8 SHIELD TO BE FOLDER AND PLACED UNDER THE CONNECTOR CABLE TIGHTENER 2.2 DIGITAL LOAD CELLS...

  • Page 11: Connection Of Load Cells To Indicator

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 2.3 CONNECTION OF LOAD CELLS TO INDICATOR The load cell has a digital output with an RS-485 interface (4-wire). In regards to the power supply, it needs an external continuous voltage (CC). To configure the cells it is necessary to go to the nuM.SCA >>...

  • Page 12: C16I Digital Cell Connection

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 2.3.1 C16i DIGITAL CELL CONNECTION In order to connect the C16i load cells to the indicator, a SC232/422B converter is necessary so that it is possible to connect directly on the terminal board in 232 on the pins 14 15 and 16. To do this one should enter in the step SEtuP >> SEriAL >>...

  • Page 13: Rcd Digital Cell Connection

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc By entering in Parameters >> Communication it is necessary to insert the COF format and the ASCII delimitation as shown in figure: Once the type of cell is chosen (SEE 2.3) one needs to enter the number of cells used, and the indicator shows: Cells Number.

  • Page 14: Setup Environment

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Part reserved for the Authorised Technical Personnel 3. SETUP ENVIRONMENT By "SETUP environment" we mean a certain menu inside which all the indicator operating parameters can be set. To enter it, turn on the instrument and, while the firmware version is displayed, press the TARE key for an instant. The indicator shows: “...
  • Page 15 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc FUNCTION OF THE KEYS IN THE SET-UP ENVIRONMENT FUNCTION F6, F7 Allow to scroll forwards and backwards in the menu steps or in the parameters inside a step. Fn / ENTER Allows to enter a step or confirm a parameter inside a step.

  • Page 16: Set-Up Environment Block Diagram

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 3.1 SET-UP ENVIRONMENT BLOCK DIAGRAM The following diagram represents the structure of the indicator’s set-up environment; each step has been described in detail in the paragraph 3.2. LAnG (!) En, Fr, dE, ES, Gr, it Cel.typ Num.Cel DGX mode...
  • Page 17 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc F1...F10, 0...9, F.ModE EN.KEYS POINT, TARE, (!) Enable, Disable Fn, 2ndF, C ENABLE ALL, SURE? DISABLE ALL LIST 1: F.Keys F1…F10 2nd F+F1… 2nd F+F10, Fn+F1…Fn+F10 AbiL.C (!) Enable, Disable AbiL.M (!) Enable, Disable AbiL.V...
  • Page 18 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc SEtuP (*) ConFiG SEriAL SCALE1, Anout SLot (!) SLot 1, Slot 2 SCALE2 ModE (!) AoG, Aon (!) 00000 … 65535 AoMA (!) 00000 … 65535 AoZE (!) 00000 … 65535 AoMi IN.1 IN.2...
  • Page 19 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc SEriAL PortS (!) PC.Pr.AX, PC.AX.Pr, Pr.PC.AX, Pr.AX.PC, AX.PC.Pr, AX.Pr.PC CoMPrn bAud (!) 9600, 1200, 2400, 4800, 19200, 38400, 57600, 115200 PAritY (!) None, Odd, Even Word (!) 8 bit, 7 bit StoP b (!) 1 bit, 2 bit CtS.St.
  • Page 20 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc ConFiG (*) SEL.SCA CELtyP XXXXXX EquAL (§) SLW.0 (!)– 3, H.R.0, H.R.1, FLT 0 – 3, DYN.0 - 1, DOS.0 – 3, H.R.2 – 7, DYN.2 PArAM. StAbiL. – 3, FLT.OFF, FLT.AV2, Custom Auto 0 (!) ENABLED (!) 10...
  • Page 21 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc (!) 0 … 6 Coin PriCE.d (!) 000 … 255 SYMboL bAnd1 XXXXXX XXXXXX bAnd2 XXXXXX XXXXXX bAnd3 XXXXXX XXXXXX bAnd4 XXXXXX XXXXXX bAnd5 XXXXXX XXXXXX bAnd6 XXXXXX XXXXXX hiSt (!) 0...

  • Page 22: Description Of The Steps

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 3.2 DESCRIPTION OF THE STEPS << LAnG >> FIRMWARE LANGUAGE Parameter Language Used Codepage (see section 7.2) - En English 1252 Windows Latin 1 - Fr FranÇais 1252 Windows Latin 1 - dE Deutsch 1252 Windows Latin 1...

  • Page 23: F.mode >> Scale Functioning

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << F.ModE >> SCALE FUNCTIONING << En.kEyS >> KEYS ENABLING It is possible to enable/disable each single key of the keyboard: - select the desired key with F6/F7: Status ENABLED - press ENTER to modify the setting: ○...
  • Page 24 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << F.kEyS >> FUNCTION KEYS COUPLING It’s possible to modify the function of the F1, F2…..F10 keys, and the combination of these with the 2nd F or Fn keys (i.e. “2nd F + F1”, “Fn + F2”, etc...). Through THE FUNCTION LIST, it is possible to link to a key up to 10 functions, which are executed one after the other.
  • Page 25 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Preamble function It is possible to associate also a preamble (numeric value) to the F1, F2…F10 keys. In this way, when the key is pressed, the preamble is automatically used as parameter of the function to be executed. The functions to which can be associated a preamble are: FUNCTIONS PREAMBLE VALUE...
  • Page 26 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc CODE BASIC FUNCTION DEFAULT KEY/S Scale Zero (ZERO) ZERO Cyclic zero (0.CYCLE) 2ndF + ZERO Tare Execution (TARE) TARE Activate printer (PRN-ON) Fn + 0 Simple printout (PRINT) Repetition of the last executed printout (CPY.PRN) 2ndF + F5 Change weight visualization (WEI.VIS) 2ndF + F8...
  • Page 27 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Select A+B visualization Format Linking to the Input Weigh Printout (FM.IN) Format Linking to the Output Weigh Printout(FM.OUT) Format Linking to the Single Weigh Printout (FM.SING) Customer alpha-betic search (ALP.CUS) Material alpha-betic search (ALP.MAt) Vehicle alpha-betic search (ALP.VEh) Change Of The Second Line Visualization In A+B Mode...
  • Page 28 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << dtb >> DATABASES << AbiL.C >> ENABLING CUSTOMER DATABASE It’s possible to enable or disable the CUSTOMER DATABASE: ENABLED DISABLED - Press F6/F7 to select “ENABLED” or “DISABLED”, and ENTER to confirm. - Proceed up to the last suggested field, after which it automatically exits the step.
  • Page 29 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << totAL >> TOTALIZER << WEi.Mod >> SELECTION OF WEIGHING MODE One selects the type of weighing which one wants to carry out:  nor.WGt NORMAL WEIGHING (simple input/output) With two scales, by confirming with ENTER one is asked whether to enable the “A+B” mode: DISABLED ENABLED ...
  • Page 30 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << A.inout >> AUTOMATIC IN OUT WEIGHT In this step you can enable (ENABLED) or disable (DISABLED) automatic input output function or print (SIMPLE PRINTOUT) when vehicle is selected. When this step is enabled, in the vehicle selection moment is request automatically the input weight, after, when you reselect the same vehicle will be request automatically the output weight.
  • Page 31 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc - PASSAGE BY ZERO OF THE NET WEIGHT (PASS. 0) - WEIGHT INSTABILITY (inStAb) (!) inStAb << LoGo >> TEXT UPON START-UP At the start-up of the indicator, the LCD display shows a message of 2 lines of 16 characters, which is set in this step, or a 160x32 pixel photo uploadable from Dinitools™...

  • Page 32: Setup >> Scale Configuration

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc - Once inside it, press the F5 key to print all the input texts. The LCD display shows the message “PRINT ?”: confirm with the ENTER key to print the whole input texts’ database. HELP By pressing the ./HELP key, it’s possible to see the keys list used in the menu.
  • Page 33 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << ConFiG >> METRIC PARAMETERS If various scales are connected, the scale number to be configured will be requested; the configurations inside this menu must be made for each connected scale. <<...
  • Page 34 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc See section 6 (USER MAN.REF.) for details on the functioning. (*) with approved instrument: - by confirming the setting of ENABLED or CYCLIC it is possible to modify the clearing percentage between +/-1 and +/-10 %.
  • Page 35 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc (*) << thEo.CA >> THEORETICAL CALIBRATION See section “3.3.7 THEORETICAL CALIBRATION”. (*) In case of approved instrument the parameter is not displayed. (*) << AdJ.CEL >> MANUAL ADJUSTMENT CELLS See section “3.3.5 ADJUSTMENT OF EQUALIZATION COEFFICIENT”. This parameter is visible only in case of various cells / channels forming the scale.
  • Page 36 Internal power supply (AUX output active just when printing). (!) PWrint << ProtoC >> SELECTS PROTOCOL norMAL standard protocol riPE 6 Dini Argeo repeater Alibi alibi memory protocol Cont. continuous transmission protocol For the protocol specifications, see section 5.4. (!) norMAL <<...
  • Page 37 NOTE: the 99 code is used as a broadcast address. (!) 00 << ProtoC >> SELECTS PROTOCOL StAnd Standard AFXX AF0X riPE 6 Dini Argeo 6-digit repeater riPLCd LCD repeater (for 3590E version) Mondir Uni-directional ALibi Alibi memory SMA protocol...
  • Page 38 << CtS.St. >> SYNCHRONISM SIGNAL Not used in this application. << ProtoC >> SELECTS PROTOCOL nonE no protocol Cont. continuous transmission riPE 6 Dini Argeo 6-digit repeater. riPEdC DC Repeater Eth.nEt protocol Ethernet Coin coin (!) nonE << rEM.SCA >> REMOTE SCALE CONFIGURATION (*)(§) This step allows setting the parameters for managing a remote scale (*) In case of approved instrument the step is not visible.
  • Page 39 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc the non significant digits (for example, if the transmitted string is spppppppu + CR + LF, in which s is the weight sign, ppppppp is the weight value, u is the unit of measure, one should set the value 08). (!) 01 <<...
  • Page 40 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc (!) 001 << dECiM.>> REMOTE SCALE’S DECIMALS Enter the number of scale decimals (from 0 to 5). (!) 0 << u.M. >> REMOTE SCALE’S UNIT OF MEASURE Select the unit of measure of the scale from those suggested: G, KG, t, Lb. (!) –...
  • Page 41 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << ZEro >> TRANSMISSION OF SCALE ZERO COMMAND FROM THE INDICATOR In this step one can enable the Zero scale transmission command: the command (not configurable) is Z followed by a “CR”.
  • Page 42 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc TERMINATOR LF (character 10 from ASCII table) no.tErM NO TERMINATOR (for Dini Argeo printiers, with standard print by Dinitools TM) (!) LF << dEF.Prn >> PRINTOUT DEFAULT By pressing ENTER one is asked to confirm the activation of the default printouts: the display shows “SurE?”: press ENTER again to confirm or another key to cancel the operation.
  • Page 43 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc - 1 - ONE KEY - 2 - TWO KEY - 3 - THREE KEY - 4 - FOUR KEY - 5 - FIVE KEY - 6 - SIX KEY - 7 - SEVEN KEY - 8 -...
  • Page 44 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc for example: rL.1=100 rL.2= 200 in.1=rL.oFF in.2=r.StArt - enabling in.2: one enables OUT1 and OUT2 and the dosage cycle starts. - upon reaching 100g the OUT1 disables. - upon reaching 200g the OUT2 disables and the dosage cycle ends. - by enabling in.1 the dosage cycle resets at any point.
  • Page 45 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc The same configurations are valid for: rL. 2 OUTPUT 2 (OUT2) rL. 3 OUTPUT 3 (OUT3) rL. 4 OUTPUT 4 (OUT4) rL..5 OUTPUT 5 (OUT5), EXPANSION BOARD rL..6 OUTPUT 6 (OUT6), EXPANSION BOARD rL..7 OUTPUT 7 (OUT7), EXPANSION BOARD rL..8 OUTPUT 8 (OUT8), EXPANSION BOARD rL..9 OUTPUT 9 (OUT9), EXPANSION BOARD...
  • Page 46 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc - 0 - NUMERICAL ZERO KEY - 1 - ONE KEY - 2 - TWO KEY - 3 - THREE KEY - 4 - FOUR KEY - 5 - FIVE KEY - 6 - SIX KEY - 7 -...
  • Page 47 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc See section “WEIGHT ZOOM” (USER MAN.REF.) for the functioning details. (!) Enable, 005 sec. (§) This step is visible only in case of CPWE indicator. << PoW.oFF >> AUTO SWITCH OFF One enables/disables the auto switch-off after the scale is not used for 5 minutes, with plate unloaded.

  • Page 48: Diag. >> Diagnostics Menu

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << ini.AL >> INITIALIZES ALIBI MEMORY (*) The initialisation cancels all the data stored in the Alibi memory; by pressing ENTER one is asked to confirm the operation. The display shows SURE?; press ENTER again to confirm or another key to cancel. At the end the "oK"...
  • Page 49 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << MiLLiV >> MILLIVOLT Check of the load cell signal in millivolts, in three decimals. By pressing ENTER the display shows: MILLIVOLT 0.285 (D) Millivolt and type of cells: (A)=Analogue, (D)=Digital CH=ALL DGX=ALL Checked DGX (only with DGX type of cells) Checked channel / digital load cell (With the DGX type of cells, it is the channel inside the DGX)
  • Page 50 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc To check if the A/D converter is faulty, disconnect the channel on which the faulty is detected and make a short between SIG+ and SIG-; with non faulty A/D converter a number of point proxime to 0 will be displayed. By pressing F5, it is possible to test the minimum value, present value and maximum value of the adc points <<...
  • Page 51 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << inPutS >> INPUT TEST By pressing ENTER it’s possible to test the status of the inputs; the display will show: INPUTS 1 2 3 4 5 6 7 8 0 0 0 0 0 0 0 0 in which the number on the first line identifies the input: Inputs of the motherboard...

  • Page 52: Calibration Of The Scale

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 3.3 CALIBRATION OF THE SCALE In case of various connected scales, each of them must be calibrated on its own, with its own capacity, division and unit of measure. In case of various digital cells / channels, in addition to the calibration, one must carry out the equalisation. 3.3.1 CALIBRATION PROCEDURE LAnG (!) 1 SCALE, 2 SCALES,...
  • Page 53 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc From above: 1) Enter the Setup of the instrument; (upon start-up, press for an instant the TARE key while the instrument version is displayed) 2) Set the number of scales; enter in the nuM.SCA step and select with the   arrow keys: - Remote: only for remote scale (calibrations are not carried out) - 1 SCALE - 2 SCALES...

  • Page 54: Linearization Points

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 15) Set the third range: select step CAP.2 and press ENTER, set the value (minimum 100 maximum 999999) and press ENTER. 16) Carry out the acquisition of the calibration points: select the CALib.P step and press ENTER. The instrument will request the following in this order: Number of signal linearization points: the "CALIBRATION POINTS"...

  • Page 55: Zone Of Use Different Than The Zone Of Calibration

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc KEYS’ FUNCTIONS enters a linearization point; cancels a linearization point; waits for weight stability and enters a linearization point copying both the converter points / millivolt and weight indications; waits for weight stability and enters a linearization point copying the converter points / millivolt indication; enters a linearization point copying the converter points / millivolt indication without waiting for weight stability;...

  • Page 56: Cell Equalisation Procedure

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 3.3.5 CELL EQUALISATION PROCEDURE NOTE: - this procedure may be selected only if various digital cells / channels are connected to the scale. - for this procedure it is advisable to use a weight of at least 1/3 of the capacity. 1) Enter in the instrument set-up;...

  • Page 57: Setting The Communication With Digital Cells

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 3.3.7 SETTING THE COMMUNICATION WITH DIGITAL CELLS Premise: Only load cells of the same model and the same capacity can compose two digital platforms. In the case in which one chooses a digital cell type in the CELtyP step, the following operations are required: 1) Check the correct matching of the ComAuX to the COM3 in the step SEtuP >>...

  • Page 58: Theoretical Calibration

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 3.3.8 THEORETICAL CALIBRATION Premise: it’s possible to use this procedure if one does not have a sample weight available for carrying out a real calibration. 1) Follow the steps described in section 3.3.1 up to point 15; 2) Select the SEtuP >>...

  • Page 59: Remote Scale Configuration

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 3.4 REMOTE SCALE CONFIGURATION Example of configuration with a DFW06 as remote scale set with extended string: [CC]B,hh,NNNNNNNNNN,YYTTTTTTTTTT,PPPPPPPPPP,uu,(dd/mm/yybbhh:mm:ss|"NO DATE TIME") <CR LF> in which: [CC] INSTRUMENT CODE IN THE FORMAT OF TWO ASCII DECIMAL DIGITS JUST IN CASE THE 485 PROTOCOL IS SELECTED (FOR EXAMPLE 00) scale number (always 1).

  • Page 60: Display Of The Scale Gravity Acceleration And Correction Of The Weighing Error Due To The Different Gravity Attraction Between The Calibration And Utilisation Zone

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Parameters to set in the setup environment: Parameter Extended String EnAb. Enable tErM WEi.PoS WEi.LEn W.tyPE tAr.PoS tAr.LEn tAr.tYP Str.LEn CAPAC. (#) XXXXXX diV. (#) dECiM. (#) u.M. (#) StAb. In.Str? Instability string position Instability string...

  • Page 61: Serial Outputs

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 5. SERIAL OUTPUTS The indicator is fitted with three serial ports, both having the output in ASCII code compatible with a wide range of printers, remote displays, PCs and other devices; in the SET-UP ENVIRONMENT one is allowed to match these ports with any available configuration (“ComPC”, “ComPrn”...

  • Page 62: Rs 485 Connection

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc !! IMPORTANT !! THE CONNECTION AND THE SOFTWARE CONFIGURATION OF THE SERIAL PORTS MUST BE MADE BY TECHNICAL PERSONNEL WHO KNOWS THE PROCEDURES ON THE BASIS OF THE USER’S NEEDS. The data transmission cable must be kept away from the AC power supply lines.
  • Page 63 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc This implies that the maximum distance can not be covered with the maximum possible speed. For an approximate value, one can consult the following table: Baud rate Total capacity of the cable (pF) 1200 400000...

  • Page 64: Pc Connection

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc In case of connection with non Dini Argeo devices, there may be different ways of line marking: generally one  presumes that the A/B indication corresponds to the +/- and HI/LO markings, but this is not always true. Therefore, if the device does not function, one should try inverting the connections even if everything seems to be correct.

  • Page 65: Transmission Protocols

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 5.4 TRANSMISSION PROTOCOLS STANDARD [available in ComPc, ComPrn, ComAux] The weight data transmission on the serial port happens in the following format: [CC]HH,KK,PPPPPPPP,UM<CR LF> In which: [CC] = instrument code, es.00 (only with RS485 protocol) HH = Underload Overload...
  • Page 66 DINI ARGEO REPEATER [available for ComPc, ComPrn, ComAux] Transmission protocol for connection to a Dini Argeo weight repeater. It transmits the weight value shown to the Dini Argeo weight display. NOTE: In this case, the setting of the SEtuP >> SEriAL >> CoM PC >> PC.ModE parameter has no relevance.

  • Page 67: Transmission Modes

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc riP. b [available in ComPc] The transmission of the weight data on the serial port takes place in the following format: $FPPPPP <CR> in which: $ = ASCII decimal character 36 (ASCII hexadecimal 24H). 0 with stable weight;...

  • Page 68: Serial Commands Format

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc TRANSMISSION ON STABILITY [available in ComPC] Transmission is automatic each time the weight put on the platform reaches stability ("~" pilot light off); the minimum transmission limit is of 10 divisions with a NON APPROVED instrument and 20 divisions with an APPROVED instrument. The reactivation of the transmission takes place depending on how the F.modE >>...
  • Page 69 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc COMMANDS Version reading: [CC]VER<CR LF> Instrument’s answer: [CC]VER,vvv,E-AF03b<CR LF> in which: vvv is the firmware version Data reading: [CC]READ<CR LF> or: [CC]R<CR LF> Instrument’s answer: see section 5.4. Semiautomatic tare: [CC]TARE<CR LF>...
  • Page 70 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Temporary view of message on the display: [CC]DISPNNVVVVVV<CR LF> in which: NN: display number of the indicator, (00 for 3590E LED display / CPWE weight section, 01 for 3590E LCD display / CPWE data section) V: character to be displayed (at least 1, cut off at the number of characters which may be viewed by the indicated display) The message remains for the time configured through the DINT command;...
  • Page 71 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Reading of converter points relative to the weight: [CC]RAZF<CR LF> Instrument’s answer: [CC]SS,RZ,RRRRRRRRRR,vv<CR LF> In which: Underload Overload Stability of the weight Instability of the weight RRRRRRRRRR Value of converter points (10 characters) Reading of microvolts relative to the weight: [CC]MVOL<CR LF>...
  • Page 72 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc AFXX type string reading and scale information: [CC]RALL<CR LF> Instrument’s answer: [AFXX string] B,NNNNNNNUM,LLLLLLLUM,SSS,AAA,CCC,TTT,XXXXX-YYYYYY<CR LF> In which: Number of platform on which the totalisation has been made. NNNNNNNUM Last net weight totalized with unit of measure. LLLLLLLUM Last gross weight totalized with unit of measure.

  • Page 73: Advanced Commands

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 5.7 ADVANCED COMMANDS [GKBB] Reading of the data in the keyboard buffer: This following command allows for the reading of the data in the keyboard buffer (max 20 keys) (only if the transmission of the pressed keys code is disabled): Syntax Format...
  • Page 74 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc A bit is ascribed to each output: Expansion board outputs (optional) Motherboard outputs OUT 16 OUT 15 OUT 14 OUT 13 OUT 12 OUT 11 OUT 10 OUT 9 OUT 8 OUT 7 OUT 6 OUT 5...
  • Page 75 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc A bit is ascribed to each input: Unhandled bits Expansion board inputs (optional) Motherboard inputs in.8 in.7 in.6 In.5 in.4 in.3 in. 2 in. 1 Therefore if the INPU00026 string is received, the hexadecimal value, converted into binary, indicates that the status of the inputs is the following: Unhandled bits Expansion board inputs (optional)
  • Page 76 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc [INUA] Request of a numeric value entry on the 3590E LCD display / CPWE-CPWET data section: Syntax Format <CC>INUA<PP><LL><I><CR LF> Parameters PP = decimal position from which the entry of the numeric data starts, from left to right.
  • Page 77 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc [GINR] Reading of entered data: GINR + CR + LF Syntax Format <CC>GINR<CR LF> Parameters Answer Entry of value on the 3590E LCD display / CPWE-CPWET data section case: - 1 if one exits from the entry phase with the C key; Entered value in decimals and confirmed with ENTER;...
  • Page 78 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc [TOPR] Transmission of numeric and/or alphanumeric string to printer: Syntax Format <CC>TOPR<XXX…X> <CR LF> Parameters XXX…X = numeric and/or alphanumeric string which one wants to print Answer <CC>OK<CR LF> The answer does not imply that the command has been made. Example 01TOPRABCDE<CR LF>...
  • Page 79 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Simulation of key pressing: [CC]KEYPXX<CR LF> in which XX is the code of the pressed key: CODE PRESSED KEY F1 key F2 key F3 key F4 key F5 key F6 key F7 key F8 key F9 key...

  • Page 80: Alibi Memory

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Read selected positon in database: [CC]GREC,X<CR LF> Instrument’s answer: [CC]GREC,X,PPPP<CR LF> In which: database index: customer database material database input text database vehicle database PPPP Position number selected in the database ( NULL if no position has been selected) Reading of compiled positions and total number of positions in the database: [CC]NREC,X<CR LF>...
  • Page 81 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 5.8.1 SERIAL COMMANDS FOR MANAGING THE ALIBI MEMORY: !! IMPORTANT !! If the serial commands are transmitted in the format: <ESC> command <STX> in which: <ESC> is the ASCII decimal 27 character <STX>...

  • Page 82: Customisation Of The String

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Instrument answer: [II]B,LLLLLLLLLLUU,YYTTTTTTTTTTUU <CR o CRLF> in which: [II] 485 address (only in the case of 485 transmission mode) number of selected channel comma character, ASCII 044 LLLLLLLLLL gross weight on 10 digits unit of measure comma character, ASCII 044 2 spaces in the case of null tare or semi automatic tare, PT in the case of preset tare...

  • Page 83: Network Management

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 6. NETWORK MANAGEMENT If in the indicator there is an ethernet board (SETHNET) it is possible to create a network between two or more instruments. If there are only two indicators the connection is made through a crossed Ethernet cable, while for the connection of more than two instruments it is necessary to use a switch/access point.

  • Page 84: Network Functions

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 568A pin 1 = White/green pin 2 = Green pin 3 = White/orange pin 4 = Blue pin 5 = White/blue pin 6 = Orange pin 7 = White/brown pin 8 = Brown 568B pin 1 = White/orange pin 2 = Orange...

  • Page 85: Self-Service

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 7. SELF-SERVICE With self service mode is possible to save automatically the weight data of all the trucks. Follow the procedure below: 1. Unload the platform 2. Place the truck on the scale 3.
  • Page 86 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << t.MonEY >> TIME MAX WAIT MONEY: (only with coin box and with the COIN protocol enabled) Maximum money wait time before, in any case, declaring that the operation is finished. The time is reset each time money is inserted. <<...

  • Page 87: Badge Reader

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 7.2 BADGE READER To configure it, connected the SERIAL of the BADGE READER (is hidden in one of the cable ducts inside the panel, not on the door) to the PC and with a program to send a serial command, you have to send this command to the READER: {1B}M2 The READER, if it has properly receive the command, it will answer –M2 From this point the READER will only function in data transmission.
  • Page 88 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc VEHICLE 3 >> PLATE: DDDDD >> DESCRIPTION: 06004 (badge number) For the search of the vehicle with the BADGE These parameters must be set:: - KEYuSE on “CONNECTED TO A BARCODE READER” - FREE TEXT AUTOMATIC COMPILATION THROUGH BAR CODE on “ENABLED”...

  • Page 89: Coin Box

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 7.3 COIN BOX Connecting the COIN BOX to the 3590E COIN BOX INDICATOR “RM5 EVOLUTION” Connection to terminal block of 3590E 1 = GND 16 = GND 2 = +5VDC 3 = TX 15 = RX 4 = RX...
  • Page 90 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 5) Send the configuration to the COIN BOX (button “Write”) 6) Test the configuration positioning in the TAB “Hardware” enabling the section Test Value Try the introduction of the coin The COIN BOX works from default by euro In order to use the coin box it is necessary to configure the parameters which are found in the COIN protocol: SEtuP >>...

  • Page 91: Rfid Reader

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc << bAnd3 >> BANDS 3 WEIGHT/PRICE: threshold for setting a price for the third weight range. << bAnd4 >> BANDS 4 WEIGHT/PRICE: threshold for setting a price for the fourth weight range. <<...
  • Page 92 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Select the right COM and push the Detect button and if everything goes well you will see a screen like this: Where you will see in the list the module detected. If the software has detected the READER correctly It will be possible to start the “Run Quick Start Wizard”...
  • Page 93 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Make sure that the selection is as described above, so proceed with next and it will appear a screen like this:...
  • Page 94 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Make sure that the selection is as described above, so proceed with Next (in this case is important that the mode is Scan Mode) and it will appear a screen like this: Send the configuration to the READER by pressing Apply and if all goes well, you will see a screen like this:...
  • Page 95 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc That indicates the succes or failure which must be crearly “No errors or warnings found” like above. If so, end the procedure with the end key, otherwise repeat the whole. 3590E/EGT Configuration To use the RFID you must enable the step Setup >>...
  • Page 96 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc - In the following screen: For the search of the Vehicle with an RFID These parameters should be set: - KEYuSE on “CONNECTED TO A BARCODE READER” - REAdEr on “AUXILIARY PORT” - FREE TEXT AUTOMATIC COMPILATION THROUGH BAR CODE on “ENABLED”...

  • Page 97: Analogue Output (Optional)

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 8. ANALOGUE OUTPUT (OPTIONAL) Through an optional interface, it is possible to use an analogue output a 16 bit configurable at 0 – 10V, 0 – 20 mA or 4 – 20 The voltage and the output current from the interface are proportional to the gross weight or net weight present on the scale In regards to the electrical connection scheme, see section 8.

  • Page 98: Output On The Net Weight

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 8.1.2 OUTPUT ON THE NET WEIGHT The value of the analogue output grows proportionally to the net weight on the scale in relation to the value configured for the net weight at 0 (AO ZE), and the one configured fo the net weight equal to the capacity (AO MA). When the gross weight is equal or greater than the capacity + 9e, the output takes on the value set for AO MA, while in the underload condition (gross weight <= -100d with approved instrument) the output takes on the value set for AO MI.

  • Page 99: Configuration

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 8.2 CONFIGURATION In order to configure the parameters, one needs to enter the SET-UP environment in the Anout step inside the SEtuP menu: If various scales are connected (see the nuM.SCA parameter), the number of the scale to be configured, will be requested; the configurations within this menu must be carried out for each connected scale.

  • Page 100: Programming The Printouts

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 9. PROGRAMMING THE PRINTOUTS It is possible to programme 30 different formats to be linked to 11 print functions: “S.F.01” function >> print key “S.F.02” function >> partial total “S.F.03” function >> general total …...
  • Page 101 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc in which: XXX is the value to be modified. Enter a valid value and press the ENTER key to confirm. Once programmed all the desired lines one should enter in the last line block 300 (PRINT END); Press the C key to exit;...

  • Page 102: Programming Example

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 9.1 PROGRAMMING EXAMPLE One programmes a format to be linked to a PRINT key function (S.F.01 function) in this way: MARIO ROSSI SRL MARIO ROSSI SRL 1/02/2005 – 19:00:00 Date – time GROSS 2.000kg Gross weight...

  • Page 103: Ascii Code Tables

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 9.2 ASCII CODE TABLES 9.2.1 CODE PAGE 1252 WINDOWS LATIN 1...

  • Page 104: Code Page 1251 Windows Cyrillic

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 9.2.2 CODE PAGE 1251 WINDOWS CYRILLIC...

  • Page 105: Code Page 1253 Windows Greek

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 9.2.3 CODE PAGE 1253 WINDOWS GREEK...

  • Page 106: List Of Print Blocks

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 9.3 LIST OF PRINT BLOCKS LEGEND: indicates a space character (ASCII 32 decimal character). unit of measure of the active scale (kg, bg, bt, lb). unit of measure of the database (kg, bg, bt, lb). terminator: depending on the setting of the SEtuP >>...
  • Page 107 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc END PAGE UPSIDE DOWN FOR TM295 This command causes the ticket to be expelled in the insertion area. ACTIVE SCALE NUMBER SCALEbNUMBERbX + T in which X is the active scale number. JUST ACTIVE SCALE NUMBER in which X is the active scale number.
  • Page 108 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc JUST 1 OUTPUT WEIGHT XXXXXXXX in which XXXXXXXX is the value of the first stored output weight, including the comma. JUST OUTPUT TRAILER WEIGHT XXXXXXXX in which XXXXXXXX is the value of the trailer output weight, including the comma. NOTE: the block is ignored if the trailer weight has not been enabled.
  • Page 109 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc CUSTOMER JUST 1 CUSTOMER CONDITIONED DESCRIPTION XXXXXXXXXXXXXXXXXXXXXXXXX + T in which XXXXXXXXXXXXXXXXXXXX are the 25 description characters; just the entered characters are printed, expanding from left to right. This block can be printed only once, in input or in output. JUST 2 CUSTOMER CONDITIONED DESCRIPTION XXXXXXXXXXXXXXXXXXXXXXXXX + T...
  • Page 110 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc in which XXXXXXXX is the total of the LOADED weight relative to the selected material. NET TOTAL MATERIAL NETbTOTALb:bXXXXXXXXUM + T in which XXXXXXXX is the difference between the ENTERED TOTAL and the EXITED TOTAL relative to the selected material.
  • Page 111 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc CONDITIONED VEHICLE VEHICLEb::XXXXXXXXXXXXXXXXXXXX + T in which XXXXXXXXXXXXXXXXXXXX are the 20 description characters; only the entered characters are printed, expanding from left to right; if the vehicle is not selected, the block is ignored. The block can just be printed once, either in input or in output.
  • Page 112 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc JUST INPUT 7TEXT HEADING XXXXXXXXXXXXXXXX JUST INPUT 8 TEXT HEADING XXXXXXXXXXXXXXXX JUST INPUT 9 TEXT HEADING XXXXXXXXXXXXXXXX JUST INPUT 10 TEXT HEADING XXXXXXXXXXXXXXXX JUST INPUT 11 TEXT HEADING XXXXXXXXXXXXXXXX JUST INPUT 12 TEXT HEADING XXXXXXXXXXXXXXXX JUST INPUT 13 TEXT HEADING XXXXXXXXXXXXXXXX...

  • Page 113: Numerical Order

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc ACTIVE SCALE NUMBER WITH ALIBI MEMORY PRINTS ALIBI MEMORY WEIGH ID XXXXXX in which XXXXXX indicates the weight ID on 6 digits, including the comma; the field expands from right to left. ALIBI MEMORY UNIT OF MEASURE UM+T this block prints the unit of measure of the weigh saved in the alibi memory.
  • Page 114 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc JUST INPUT 10 TEXT HEADING XXXXXXXXXXXXXXXX JUST INPUT 11 TEXT HEADING XXXXXXXXXXXXXXXX JUST INPUT 12 TEXT HEADING XXXXXXXXXXXXXXXX JUST INPUT 13 TEXT HEADING XXXXXXXXXXXXXXXX JUST INPUT 14 TEXT HEADING XXXXXXXXXXXXXXXX JUST THE INPUT 0 TEXT CONTENTS YYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYY in which YYYYYYYYYYYYYYYYYYYYYYYYYYYYYYYY are 32 characters of the input 0 text contents;...
  • Page 115 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc SCALE UNIT OF MEASURE DATABASE UNIT OF MEASURE TICKET PROGRESSIVE XXXXX (progressive number that is increased with each input/output weighing cycle and upon each single weigh) LOT PROGRESSIVE XXXXXX (number of general total resettings) NET CUSTOMER TOTAL N.YYYbTC.N.XXXXXXXXbUM + T in which YYY indicates the number of weighs, XXXXXXXX is the weight value on 8 digits including the comma.
  • Page 116 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc JUST “PT” TEXT PTb: JUST “CUSTOMER” TEXT CUSTOMERb: JUST “MATERIAL” TEXT MATERIALb: JUST “CUSTOMER TOTAL” TEXT CUSTOMER TOTAL + T JUST “MATERIAL TOTAL” TEXT MATERIAL TOTAL + JUST “NET” TEXT NETb: JUST WEIGHT ID VALUE In which XXX is the weigh number, from 1 to 999;...

  • Page 117: Active Scale Number With Alibi Memory

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc expanding from left to right; if the material is not selected, the block is ignored. The block can be printed several times, either in input or in output. JUST 1 CUSTOMER DESCRIPTION XXXXXXXXXXXXXXXXXXXX in which XXXXXXXXXXXXXXXXXXXX are the 20 description characters;...

  • Page 118: Last Tare On Alibi Memory

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc either in input or in output. CONDITIONED VEHICLE VEHICLEb:XXXXXXXXXXXXXXXXXXXX + T in which XXXXXXXXXXXXXXXXXXXX are the 20 description characters; only the entered characters are printed, expanding from left to right; if the vehicle is not selected, the block is ignored. The block can just be printed once, either in input or in output.

  • Page 119: Blocks With Parameters

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc PRINTS OPERATION SYMBOL In which X is “+” in case of addition, “-“ in case of subtraction, “x” in case of multiplication. The 482, 483, 484 and 485 blocks refer to the operation executed with the “calculator” function described in section 15.1, USER MAN.REF.
  • Page 120 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Parameter Result 100.01 0000100.01 0000010001 ################ CONDITIONING THE 1 CUSTOMER DESCRIPTION PRINTING Valid values 000 or 001 000  The previous macro can be printed a second time. 001  The previous macro will not be printed a second time. This macro is valid for the CONDITIONED macros which print the first description of the customer.
  • Page 121 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc XX is the threshold beginning if n = 0 or the characters to be printed if n = 1. PRINTS WEIGHT ID VALUE Values valid in the nXX format In which n can be: Value with decimal point and spaces Value with decimal point and zeros in the place of spaces Value without decimal point and zeros in the place of spaces...
  • Page 122 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc If one needs to manage various printers using the available relays (connecting the transmission of the printer port on the common of the relays), follow the example below: PRINTING OF THE NET WEIGHT ON RELAY 1, GROSS ON RELAY 2, TARE ON RELAY’ 3. …...
  • Page 123 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc XX is the number of formatting characters. See the example in the 624 macro. SETTING THE FILLING CHARACTER OF THE FOLLOWING MACRO Values valid in the XXX format This macro allows to set the filling character of the following macro. XXX corresponds to the ASCII decimal character (from 001 to 255).
  • Page 124 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc Net grand total Article gross total Partial gross total General gross total Gross grand total Tare article total Partial tare total Tare general total Tare grand total Weighs’ material total Weighs’...
  • Page 125 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc SETS UNIT OF MEASURE IN THE ACCUMULATOR VALUE Values valid in the XXX format in which XXX can be: NOTE: if no unit of measure has been set, the one of the scale is used. PRINTS THE LOADED VALUE IN THE ACCUMULATOR Values valid in the nXX format In which n can be:...
  • Page 126 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc ################ EXAMPLE … 647 >>> enter parameter 001 The following macros will be printed without terminator 647 >>> enter parameter 000 The following macros will be printed with the terminator …...

  • Page 127: Display Customization

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc SET THE FUNCTION 0xx set the code of the function that one want to perform. Example: To execute the function 311 is necessary insert in the format the macro 651 with 003 parameter (that set the level menu level) and the macro 652 with 011 parameter (number of the function).

  • Page 128: Electrical Schemes

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 11. ELECTRICAL SCHEMES 11.1 MOTHER BOARD OUTPUTS 60Vdc 0.15 A max 48Vac 0.15 A max INPUTS 12Vdc – 24Vdc 20mA max J9 (ON): - If closed, one can automatically turn on the instrument as soon as the power voltage is supplied; one must also turn off the instrument by removing the mains voltage.
  • Page 129 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc J13 (+Vdc OUT): allow selecting the power voltage (+6V, +12V) of terminal board 21(+Vdc) output. By selecting +6V the battery must be connected on terminal 3 and 4 By selecting +12V the external power supply must be connected on terminal 1 and 2 Therefore one has to verify if the battery or the external power supply is necessary for the required output, otherwise no voltage will be supplied on the terminal 21.
  • Page 130 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc !! IMPORTANT !! The input/output optoisolation is obtained by feeding the input and/or output common using a voltage external the instrument. RS232 SERIAL PORT (RJ45 CONNECTOR) (*) PLUG6 CONNECTIONS: PLUG6 COLOUR MEANING ORANGE-WHITE...
  • Page 131 3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 11.2 I/O EXPANSION BOARD (fitted with 3590EXT in IO version or CPWE) INPUTS 12Vdc – 24Vdc 20mA max ANALOGUE OUTPUT I/O1 (SLOT 1): I/O2 (SLOT 2): Note: the maximum resistance applicable on the analogue 53 I+ (A1) + 20 mA 56 I+ (A2)

  • Page 132: Display Board

    3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc 11.3 DISPLAY BOARD PC-Keyb – PC KEYBOARD CONNECTOR Keyboard emulation input, usable for the connection of the instrument to the PC keyboard or the badge/bar code reader. PC-KEYB PS/2 DATA 11.4 CONTROL LIGHT (only for CPWET) J1: if closed, allows to set the power supply of the control light to 6V.

This manual is also suitable for:

3590exp series3590ext series3590 ebox seriesCpwe seriesCpwet series

Table of Contents

Save PDF
