Single Element Immersion Heaters
1)
Connect the Neutral to Terminal 3.
2)
Connect the Earth to the Earth terminals.
3)
Connect the Live to both Terminal 4 and Terminal 5.
Dual Element Immersion Heaters
1)
The heaters should be controlled through separate thermostats. In practice
the thermostat for the top (short) element is usually set 5 – 10 °C less than the
thermostat for the (long) O Peak element.
2)
Connect the Neutral to Terminal 3.
3)
Connect the Earth to the Earth terminals.
4)
Connect the short element (Boost Load) to Terminal 4.
5)
Connect the long element (Timed/O Peak Load) to Terminal 5.
Note:
The 3 core exible cable from the immersion heater to the IMC controller should be heat resistant
ƒ
and rated to 85˚C.
Immersion Controller
9
