(7) Example Circuit Connection (J4)
ADB-5F41EL
190Ω
Photo-coupler
190Ω
Photo-coupler
190Ω
Photo-coupler
+5V
GND
● + 5V and GND are not insulated from the internal power supply of the ADB-5F41EL.
(J4 )
A
1
A
2
B
3
B
4
Z
5
Z
6
+5V
7
GND
8
SHIELD
9
-33-
Instructions Manual
Encode
A
Y
A
Equivalent
to 26C31
Z
B
Y
B
Equivalent
to 26C31
Z
Z
Y
Equivalent
Z
to 26C31
Z
+5V
+5V
GND
GND
SHIELD
ADB-5F41EL
