  • Page 1 Toll Free: 1-888-865-6888 Tel: 510-226-8368 Fax: 510-226-8968 Email: sales@RackmountMart.com...
  • Page 2 User Manual 16.2” High Resolution 1920 x 1200 LCD ID-E17Aw Aluminum front bezel ID-E17AwN Front NEMA4 / IP65 ID-E17Dw Aluminum front cover ID-E17Pw Universal Mounting Open Frame...
  • Page 3 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.

  • Page 4: Table Of Contents

    Contents < Part. 1 > ID-E17Aw / ID-E17AwN Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation P.4 - 5 ID-E17Dw < Part. 2 > Package Content Structure Diagram & Dimension P.7 - 8 Mounting Hardware & Installation <...
  • Page 5 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
  • Page 6 < Part 1 > < 1.1 > Package Content - ID-E17Aw / ID-E17AwN 16.2” High Resolution LCD display X 1 6ft VGA cable X 1 Power cord X 1 Remote controller X 1 Mounting hardware X 1 pack - Mounting bracket x 4 pcs...

  • Page 7: Id-E17Aw Id-E17Awn

    < 1.2 > Structure Diagram - ID-E17Aw / ID-E17AwN Front view Rear case Rear view LCD panel 6mm aluminum front bazel Audio speaker, pair LCD membrane Remote sensor Product Dimension Model (W x D x H) Weight 468.5 x 57.1 x 331 mm 4.9 kg...
  • Page 8 < 1.2 > Dimension - ID-E17Aw / ID-E17AwN Front View Side View Rear View UNIT : mm 1mm = 0.03937 inch Bottom View www.RackmountMart.com...

  • Page 9: Mounting Hardware & Installation

    < 1.3 > Panel Mount Installation - ID-E17Aw / ID-E17AwN M4*50mm screw M4*6mm screw Mounting bracket x 8 pcs x 8 pcs x 4 pcs Steps ■ Install 4 mounting brackets with 8 x M4*6mm screws ■ Adjust the LCD panel with 8 x M4*50mm screws and fi x it on the surface.
  • Page 10 < 1.3 > VESA mount Installation - ID-E17Aw / ID-= E 17AwN M4 screw VESA mount ( 100*100mm ) ■ Hardware and M4*4 pcs for VESA mount are not provided www.RackmountMart.com...

  • Page 11: Package Content

    < Part 2 > < 2.1 > Package Content - ID-E17Dw 16.2” High Resolution LCD display X 1 6ft VGA cable X 1 Power cord X 1 Remote controller X 1 Basic I/O Audio Power S-Video DVI-D HDMI out - in - in Video PC - An abundance of input connections that include HDMI, DVI-D, VGA, S-Video + BNC and audio - On-chip Faroudja®...

  • Page 12: Part. 2 > Id-E17Dw

    < 2.2 > Structure Diagram - ID-E17Dw Front view Side view Rear view Rear case LCD panel Front cover Audio speaker, pair LCD membrane Product Dimension Model (W x D x H) Weight 437.5 x 51.9 x 300 mm 4.4 kg ID-E17Dw 17.2 x 2 x 11.8 inch 9.7 lbs...
  • Page 13 < 2.2 > Dimension - ID-E17Dw Front View Side View Rear View UNIT : mm 1mm = 0.03937 inch www.RackmountMart.com...
  • Page 14 < 2.3 > VESA Installation - ID-E17Dw VESA mount ( 100*100mm ) ■ Hardware and M6*4 pcs for VESA mount are not provided www.RackmountMart.com...

  • Page 15: Package Content

    < Part 3 > < 3.1 > Package Content - ID-E17Pw 16.2” High Resolution LCD display X 1 6ft VGA cable X 1 Power cord X 1 Remote controller X 1 Basic I/O Audio Power S-Video DVI-D HDMI out - in - in Video PC - An abundance of input connections that include HDMI, DVI-D, VGA, S-Video + BNC and audio - On-chip Faroudja®...

  • Page 16: Part. 3 > Id-E17Pw

    < 3.2 > Structure Diagram - ID-E17Pw Front view Rear case Rear view LCD panel Audio speaker, pair Universal open frame mounting LCD membrane Extended remote sensor membrane cable ( 66cm from AD board to sensor end ) Product Dimension Model (W x D x H) Weight...
  • Page 17 < 3.2 > Dimension - ID-E17Pw Front View Side View Rear View UNIT : mm 1mm = 0.03937 inch Bottom View P.12 www.RackmountMart.com...
  • Page 18 < 3.3 > Installation - ID-E17Pw ( I ) Universal mount ( II ) VESA mount ( 100*100mm ) M4 screw Hardware and M4*4 pcs for VESA mounting are not provided P.13 www.RackmountMart.com...

  • Page 19: Product Specifi Cations

    < Part 4 > < 4.1 > Product Specifi cations Mechanical ID-E17Aw ID-E17AwN ID-E17Dw ID-\ E 17Pw Design Protection 6mm front cover NEMA 4 / IP 65 front cover open frame Front Panel Black, RAL 9005 Rear Casing Black, RAL 9005...
  • Page 20 Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 5~500Hz 1G RMS random ID-E17Aw / AwN ID-E17Dw ID-E17Pw Physical Specifi cation Product 468.5 x 57.1 x 331 mm 437.5 x 51.9 x 300 mm 465.5 x 50.9 x 368 mm ( W x D x H ) 18.4 x 2.2 x 13 inch...

  • Page 21: On-Screen Display Operation ( Osd )

    < 4.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &...
  • Page 22 < 4.2 > On-screen Display Operation ( OSD ) Audio Audio mode : Movie / Voice / Normal / Music mode to choose Volume : Adjust the volume of sound Bass : Set the value of bass sound Treble : Set the value of treble sound Balance : Set the balance value of treble and bass sound...

  • Page 23: Picture In Picture ( Pip ) / Picture By Picture ( Pbp )

    < 4.3 > How to Use Picture In Picture ( PIP ) / Picture By Picture ( PBP ) < 4.3.1 > Picture in Picture ( PIP ) Mode Display the Sub screen in the Main screen. OSD Menu → MISC → PIP Mode → Large / Small / OFF Main screen Sub screen Position...
  • Page 24 < 4.3 > How to Use Picture In Picture ( PIP ) / Picture By Picture ( PBP ) < 4.3.2 > Picture By Picture ( PBP ) Mode Display the Sub screen next to the Main screen. OSD Menu → MISC → PIP Mode → PBP Main screen Sub screen Size...

  • Page 25: Remote Controller

    < 4.4 > Remote Controller INPUT MUTE -/-- FREEZE AUTO MENU SELECT ASPECT SLEEP ENTER BACK EXIT SWAP SOURCE POSITION AUDIO INPUT Select the source Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 0 - 9 and above, enter the second digit within two seconds.

  • Page 26: Part 5 > Options

    < Part 5 > Options < 5.1 > Option Table Options Aw / Dw SDI *** Touchscreen MCS multi-display control *** DC Power MIL-type / lockable connector P.21 www.RackmountMart.com...
  • Page 27 < 5.2 > Options : 3G / HD / SD-SDI input Our SDI input is an ideal solution for the broadcast-grade video and high resolution CCTV market. Designed for use with NOVA series displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 1-year warranty.
  • Page 28 More control is always good. Especially when it is necessary and ( Multi-display Control ) easy. Synergy Global Technology provides MC solution to control the OSD of various Industrial LCD displays up to 64 units. The RS-232C is used for the communication between the PC and the fi...

  • Page 29: Resistive / Capacitive ( 1-Point Touch )

    < 5.4 > Options : Touchscreen & driver 17 USB Touchscreen Specification Model Resistive Capacitive Technology 5-Wire Resistive Capacitive Touch Point Single Single Input Type Finger or Stylus Finger Resolution 2048 x 2048 2048 x 2048 Touch Point Accuracy Response Speed 15 ms 20 ms Activation Force...
  • Page 30 < 5.4 > Options : Touchscreen & driver TRB / TCB Driver Please follow the below steps to setup the touch screen:- Step 1. Run the bundled CD disc or download the driver from the link below : http://www.rackmountmart.com/downloads.html Step 2. Double click the Setup.exe Step 3.
  • Page 31 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2018 Synergy Global Technology Inc. All rights reserved. P.26 www.RackmountMart.com...
