Rhino-Rack RBC035/036 HD/ VA Fit Kit Rear Bar (RBCA026)
RBCA026 to be used in conjunction with RBC035 & RBC036
Item
Component Name
*1a
M6 x 12mm Security Bolt
*1b
M6 x 20mm Security Bolt
2
M6 Spring Washer
3
M6 Flat Washer
4
RBCA Bracket
5
M6 Channel Nut
6
Torque Allen Key
7
Fitting Instruction
*M6x20mm Security to be used with HD Bars
*M6x12mm Security to be used with VA Bars
Note: RBCA026 is compatible with the following Bars
RAB
Sportz
RBCA026
Parts List
Qty
Part No.
1
B148
1
B062
1
W004
1
W031
1
CA1254
1
N002
1
TORKEY-S
1
R361
SXB
Heavy Duty
VA
6.
1.
2.
3.
4.
5.
Page 1 of 3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rhino-Rack RBCA026
Summary of Contents for Rhino-Rack RBCA026
- Page 1 Rhino-Rack RBC035/036 HD/ VA Fit Kit Rear Bar (RBCA026) RBCA026 Parts List RBCA026 to be used in conjunction with RBC035 & RBC036 Item Component Name Part No. M6 x 12mm Security Bolt B148 M6 x 20mm Security Bolt B062 M6 Spring Washer...
- Page 2 Rhino-Rack RBC035/036 HD/ VA Fit Kit Rear Bar (RBCA026) Slide Item 1 through Item 2 and Item 3. These will then be placed through Item 4 as shown. Item 1 Item 2 Item 3 Item 4 Loosely attach Item 5 as shown.
- Page 3 Rhino-Rack RBC035/036 HD/ VA Fit Kit Rear Bar (RBCA026) IMPORTANT Heavy Duty bars (HD) will reffer to steps 4a,b. VA,Sportz, SXB and RAB will use steps 5 a,b. HD BAR ONLY: Slide Item 5 into the HD Bar C Item 5 will slide into HD bar as shown.
