Submersible Turbine Grinder Pump
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
INSTALLATION MANUAL
83 West Drive, Bramton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
Series: PGPT
1 HP, 3450 RPM, 60 Hz.
(PUMP ONLY)
Form No. 140868-Rev. B
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Crane Barnes PGPT Series
Summary of Contents for Crane Barnes PGPT Series
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notifi cation.
-
Page 2: Safety First
(fl ammable, caustic, etc.) unless the pump is specifi cally designed and designated to handle them. Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems Inc. 2016 Alteration Rights Reserved... - Page 3 ® USER GUIDE Congratulations on your purchase of a Barnes grinder pump generates suffi cient pressure grinder pump system. With proper care and by to pump this slurry from your home to the following a few simple guidelines your grinder wastewater plant.
-
Page 4: Pump Specifications
PUMP SPECIFICATIONS: DISCHARGE ......Bolt on fl ange with Intergrated CORD ENTRY .......Custom Molded Quick Connect for Anti-Siphon Sealing with Strain Relief. LIQUID TEMPERATURE ..104°F (40°C) Continuous CORD: MOTOR HOUSING ....Cast Iron ASTM A-48, Class 30 Type ....12/5 CSA/UL Approved SOW SEAL PLATE .......Cast Iron ASTM A-48, Class 30 SPEED: ......3450 RPM, 60Hz... - Page 5 MODEL VOLT NEMA FULL LOCKED CORD CODE CORD CORD WINDING START LOAD ROTOR SIZE TYPE O.D. LENGTH RESISTANCE CODE AMPS AMPS ± .02 (.5) Ft. (m) MAIN -- START in (mm) PGPT1022C 12.5 35.0 12/5 .71 (18) *VARIES 1.5 - 3.3 Winding Resistance ±...
- Page 6 The nameplate is located on top of the pump. This contains the pumps part number, horsepower voltage, phase, and serial number, as well as other information. The start-up form located in the back of this manual contains a place to record this data.
-
Page 7: Installation
SERVICE CENTERS: For the location of the nearest Barnes Service Center, check your Barnes representative or Crane Pumps & Systems, Inc., Service Department in Piqua, Ohio, telephone (937) 778-8947 or Crane Pumps & Systems Canada, in Brampton, Ontario, (905) 457-6223. -
Page 8: Cable Connections
Wire Size - If additional cable is required consult a qualifi ed electrician for proper wire size. CABLE CONNECTIONS: Power/Control Cable- Insert female end of cable plug into housing bore aligning alignment mark with hole in terminal block see Figures 3 & 4. Tighten bolts on compression fl... - Page 9 Wiring Harness Item 54 on Figure 8 Single phase 240 Volt AC, 60Hz, 12/5 SOW FIGURE 5...
-
Page 10: Troubleshooting
TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH “CAUSE”... - Page 11 FIGURE 6...
-
Page 12: Parts List
PARTS LIST Seal/Overhaul Kit ....p/n 138085A Cutter Kit ....... p/n 138086A Shim Kit ......... p/n 138087A ITEM PART NO. DESCRIPTION MATERIAL 136566CT Casing, PGPT, CI, Coated Class 30 CI 136571-LB Plate, Seal, PGPT Class 30 CI 137023 Shim, 6.91” O.D., 5.50” I.D. 118256 Housing, Motor/Discharge 136561... - Page 14 Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material.
- Page 15 A Crane Co. Company START-UP REPORT General Information Pump Owner’s Name: __________________________________________________________ Address: ____________________________________________________________________ Location of Installation: _________________________________________________________ Contact Person: __________________________________Phone: _______________________ Purchased From: _____________________________________________________________ Nameplate Data Pump Model #: ___________________ Serial #: _____________________________________ Part #: __________________________ Impeller Diameter: ____________________________ Voltage: _________ Phase: _____ Ø...
