Optisure Remote User's Manual
No. Name
1 Customizable Readouts
Sensor Status Display
2
3 Trend Graph
4 Operational Status Display
DCC On/Off
5
Max Cool On/Off
6
7 Standby/Operate
8 Setup
3.1.2 Customizable Readouts
The three readouts on the Main Screen can be configured by the User to show any of
the following parameters:
• Dew Point
• Temperature
• Pressure
• % Relative Humidity
• ppm
V
• % Volume
• g/kg
• g/m
3
• Temp-Dew Point
To change a parameter:
1. Touch the readout once to enable parameter selection
2. Touch the left or right arrows to select the parameter to be displayed
3. Touch the center of the readout to confirm selection
Full Screen Mode
Any of the readouts can be shown in full screen mode by touching and holding the
readout.
Kahn Instruments
Description
Display measured and calculated parameters. See
section 3.1.2 for additional information.
Displays both thermo-electric cooler (TEC) drive
and optical signal condition. See section 3.1.5 for
additional information.
Plots measured dew point over time. Time base can
be changed in display settings. Touch the readout
once to enter full screen mode.
See section 3.1.4 for a detailed description of this area
Initiates or cancels a DCC. See section 4.5.1 for an
explanation of the DCC function.
See section 3.2.1 for DCC setup parameters.
Initiates or cancels a Max Cool. See section 4.5.2 for
an explanation of the Max Cool function.
Toggles between Measure and Standby modes. When
switching to Measure mode a DCC will be initiated.
Access the Setup menu. See section 3.1.3 for
information on the menu structure and options.
Main Screen Layout
Table 3
OPERATION
15
