Item # 1004181632
Model # EBAU25-PCP
USE AND CARE GUIDE
1/4 HP SUBMERSIBLE POOL COVER PUMP
Questions, problems, missing parts? Before returning to the store,
call Everbilt Customer Service
8 a.m. - 5 p.m., EST, Monday-Friday
1-844-251-7446
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Everbilt through the purchase of this 1/4 HP submersible pool
cover pump. We strive to continually create quality products designed to enhance your home. Visit us online to see our full
line of products available for your home improvement needs. Thank you for choosing Everbilt!
Advertisement
Table of Contents
Related Manuals for Everbilt EBAU25-PCP
Summary of Contents for Everbilt EBAU25-PCP
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Everbilt through the purchase of this 1/4 HP submersible pool cover pump. We strive to continually create quality products designed to enhance your home. Visit us online to see our full...
-
Page 2: Table Of Contents
Table of Contents Package Contents ............4 Table of Contents ............2 Performance ..............2 Specifications ............. 5 Safety Information ............2 Installation ..............5 Warranty ................. 3 Operation ............... 7 Pre-installation .............. 4 Care and Cleaning ............8 Application ..............4 Troubleshooting ............ -
Page 3: Warranty
Safety Information (continued) WARNING: This unit is designed only for use on WARNING: Try to keep the pump as straight as 115 volts (single phase), 60 Hz, and is equipped possible. Do not suspend the pump by the with an approved 3-conductor cord and 3-prong discharge hose or power cord. -
Page 4: Pre-Installation
Warranty (continued) This limited warranty is in lieu of any other warranties, express or implied, including any implied warranty of merchantability or fitness for a particular purpose, or otherwise, and of any other obligations or liability on the seller’s part. This limited warranty does not cover non-defect damage, damage caused by improper installation, or care (including but not limited to abuse, misuse, failure to provide reasonable and necessary maintenance, or dismantling or for reinstalling a repaired or replaced product or component). -
Page 5: Specifications
Pre-installation (continued) SPECIFICATIONS 115V, 60 HZ Power Supply Required 32°F to 95°F (0°-35°C) Liquid Temp. Range 15 Amp Minimum Individual branch circuit required 1-1/4 in. Male NPT or 3/4 in. garden Discharge Connection hose connection 1-1/4 in. Flexible Discharge Hose or 3/4 Discharge Hose Needed in. - Page 6 Installation (continued) Connecting the discharge Placing the pump on the hose pool cover □ □ Attach a 3/4 in. garden hose (not included) to the Place the pump (A) on the pool cover. adapter (C). □ Using a pole, broom, or rake, push the pump (A) to the desired location on the pool cover.
-
Page 7: Operation
Operation Operating the pump □ Plug the pump (A) into a properly grounded outlet. The pump (A) is equipped with a Ground Fault Circuit Interrupter (GFCI) plug. If the pump is not running when it should be, check this plug to ensure it has not tripped. If it has tripped, press the button on the plug to reset. -
Page 8: Care And Cleaning
Care and Cleaning Do Not □ □ When the power is disconnected, inspect the pool Do not disassemble the motor housing. This motor cover base and the pump intake screen (bottom of has NO repairable internal parts, and disassembly pump) and remove all debris, then plug the pump may cause leakage or dangerous electrical wiring back into the grounded outlet. -
Page 9: Troubleshooting
Troubleshooting CAUTION: SHUT OFF POWER TO THE PUMP. Problem Possible Cause Corrective Action The motor runs but no water The intake screen or impeller is blocked. Clean the intake screen and impeller. is discharged or flow rate is There is an airlock in the discharge. Clean the airlock release feature (see lower than expected. - Page 10 Questions, problems, missing parts? Before returning to the store, call Everbilt Customer Service 8 a.m. - 5 p.m., EST, Monday-Friday 1-844-251-7446 HOMEDEPOT.COM Retain this manual for future use.
