SKU # 1001093932, 1001093909
1001093950, 1001093925
Model # SBA025BC, SBA033BC
SBA033V1, SBA050BC
USE AND CARE GUIDE
SUBMERSIBLE SUMP PUMP
Tethered Switch SKU # 1001093932
Vertical Switch SKU # 1001093950
SKU # 1001093909 SKU # 1001093925
Questions, problems, missing parts? Before returning to the store call
Everbilt Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-844-241-5521
HOMEDEPOT.COM
Rev. 05/20/17
THANK YOU
We appreciate the trust and confidence you have placed in Everbilt through the purchase of this submersible sump pump. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Everbilt!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Everbilt 1001093932
Summary of Contents for Everbilt 1001093932
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Everbilt through the purchase of this submersible sump pump. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Troubleshooting ............9 Pre-Installation .............. 4 Performance GPH of Water @ Total Feet Of Lift Max. Lift 0 ft. 5 ft. 10 ft. 15 ft. 20 ft. 1001093932 3000 2700 2400 1700 1000 22 ft. 1001093909, 1001093950 3400 3150 2800... -
Page 3: Warranty
Safety Information (continued) CAUTION: Know the pump and its applications, IMPORTANT: Ensure the electrical power source is limitations, and potential hazards. adequate for the requirements of the pump. CAUTION: Secure the pump to a solid base. This will aid IMPORTANT: This pump is made of high-strength, in keeping the pump in a vertical orientation. -
Page 4: Pre-Installation
Pre-Installation APPLICATION This submersible sump pump is designed for home sump applications. Use this pump only for pumping water. This unit is not designed as a waterfall or fountain pump, or for applications involving salt water or brine! Use with waterfalls, fountains, ... - Page 5 Pre-Installation(continued) PACKAGE CONTENTS NOTE: The adapter is not shown to scale. Tethered Switch SKU # 1001093932 Vertical Switch SKU # 1001093950 SKU # 1001093909 SKU # 1001093925 Part Description Pump Adapter (1-1/2 in. MNPT X 1-1/4 in. FNPT) SPECIFICATIONS Power supply 115V, 60 HZ., 15 Amp Circuit...
-
Page 6: Installation
Installation Tethered Switch SKU # 1001093932 Vertical Switch SKU # 1001093950 SKU # 1001093909 SKU # 1001093925 1. Install the pump in sump pit with minimum diameter of 10 in. (254mm) for models equipped with vertical switch and 14 in. (356 mm) for tethered float switch models. -
Page 7: Operation
Installation (continued) 7. Power Supply: Pump is designed for 115 V, 60 Hz, operation and requires a minimum 15 amp individual branch circuit. Plug the power plug into a 115V GFCI power outlet. WARNING: Risk of electric shock. Can shock, burn or kill. Pump should always be electrically grounded to a suitable electrical ground such as a grounded water pipe or a properly grounded metallic raceway, or ground wire system. -
Page 8: Care And Cleaning
Operation (continued) 3. The pump will not remove all water. If operating a pump manually, and suddenly no water comes out of the discharge hose, shut off the unit immediately. The water level is probably very low and the unit has broken prime. WARNING: Risk of electric shock Can shock, burn or kill. -
Page 9: Troubleshooting
Troubleshooting Problem Possible Cause Corrective Action The pump does not start or run. 1. No power. 1. Reset GFCI switch/Reset the 2. The impeller is blocked. breaker/Secure the plug/Clean the 3. The float switch failed. plug prongs. 4. The motor failed. 2. - Page 10 Questions, problems, missing parts? Before returning to the store call Everbilt Customer Service 8 a.m. - 6 p.m., EST, Monday-Friday 1-844-241-5521 HOMEDEPOT.COM...
