2.2.3 Control Module FC0500M-40 (internal power supply)
Control Module (FC0500-40) Display Panel
LED Button
Short Press
Long Press
(more than
5sec)
Status
2 colors, Blue and orange
Refer to [LED Indicators Instructions]
Display the LED panel for 20sec.
When status LED fast flashes blue ●, loss the button, then it is
115200 baud rate of RS485.
When status LED fast flashes orange ●, loss the button, then it
is 9600 baud rate of RS485.
8/34
