Summary of Contents for Pylontech US2000 Plus
- Page 1 External External External Power Cable - Power Cable + Power Cable -/+ Communication Cable...
- Page 2 Pylontech Out-door Cabinet Cable Connection Cables connection of lower layer 3 batteries Power Link Port 0 US2000 Plus Lithium Battery Link Port 1 Power Link Port 0 US2000 Plus Lithium Battery Link Port 1 Power Link Port 0 US2000 Plus Lithium Battery Link Port 1 In the battery modules’...
- Page 3 Unpack the corrugated box. And lift the cabinet from the box. Move the cabinet to the basement. Please use the attached 2 wide nylon belts to handling cabinet.
- Page 4 foundation Fix with the hangers (recommend) bolt Move the 2 hangers from inside to outside. Or fix the cabinet with the cabinet feet. Connect the grounding cable from basement. foundation bolt Wall Grounding Point...
- Page 5 Take away the 4 shield sleeves on the rails. Put 3 Lock the 6 dowels for these 3 batteries. batteries on the under layer. And lock the blade bolt. Align the calibration and the battery’s hole. • Connect the cables of lower layer 3 batteries. Please see < Cabinet OD Cable Connection >. Put the separate board on the 4 stop blocks.
- Page 6 Pylon Technologies Co., Ltd. No. 73, Lane 887, ZuChongzhi Road, Zhangjiang Hi-Tech Park Pudong, Shanghai 201203, China +86-21-51317697 | +86-21-51317698 service@pylontech.com.cn www.pylontech.com.cn...
