Dimensions
VZH052-065G/J/H
Version Compressor model
Single VZH052-065
Unified VZH052-065
10
AB237586440343en-000601
ΦD
L1
Single version
Terminal box
EMC bracket to terminations
of shielded wire
D H
(mm) (inch) (mm) (inch) (mm) (inch) (mm) (inch) (mm) (inch) (mm) (inch)
183.5 7.22 436 17.17 403
183.5 7.22 436 17.17 403
H
H1
H2
L2
Mounting Grommet
Earth grounding
H1 H2 L1
15.87 261 10.28 190.5
15.87 261 10.28 190.5
ΦD
H2
L1
Unified version
29.5
Ø11
Ø 41
Recommended torque for
mounting bolts: 11 Nm (±1 Nm)
L2
Outline drawing number
7.5 190.5 7.5 8590007
7.5 190.5 7.5 8590013
H
H1
L2
