Gearbox housing
Brush roller
Transport caps Lance bow
Splash guard
Telescopic lance and the modular pole
BA 0303788 R00 2019-03

Components and their function

The gearbox housing is the drive unit
of the cleaner. All components neces-
sary for the drive of the brush rollers
are installed here. The brush rollers are
mounted on the axles of the gearbox
housing. The lance is mounted to the
connection PIN.
The brush roller is the component of
the cleaner that carries out the cleaning
work. The individual elements have the
widths 240 mm and 100 mm. A cover
with bristles is mounted at the end.
The transport caps protect the brush
roller from pressure marks. They are
inserted into the end caps of the brush
roller.
The lance bow increases the contact
pressure of the brush roller on the
cleaning surface. This increases the
cleaning effect.
The splash guard protects the user
from splashing water. It reduces water
loss from spray water and increases the
wash-off effect.
The telescopic lance and the modular
pole is the handle of the cleaner. The
cleaner is used with it.
