Dual Monitor Desk Mount with VESA Adapter Bracket
Instruction Manual
SKU: STAND-V002VA
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v002va
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
309-278-5303
Chat live with an agent!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAND-V002VA and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivo STAND-V002VA

  • Page 1 Dual Monitor Desk Mount with VESA Adapter Bracket Instruction Manual SKU: STAND-V002VA Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v002va GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2: Package Contents

    WARNING! PACKAGE CONTENTS If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3: Assembly Steps

    STEP 2 - Continued ASSEMBLY STEPS OPTION B: Grommet Installation Use a Phillips screwdriver to loosen screw inside Clamp (B). Disassemble and separate the Hand STEP 1 Crank (B1) and Clamp Plate (B2). Unscrew the hand crank of Clamp (B) to create an opening for the clamp to placed on desktop. STEP 2 Install Grommet Plate (E) to the Pole (A) using M6x16 Screws (S-A) and 3mm Allen Wrench (T-B).
  • Page 4 STEP 3 OPTION #1 Slide Pole Cable Clip (L) and Swivel Arm (C) onto Pole (A). Tighten Swivel Arm (C) at desired height Install Extension Brackets (H) onto your VESA mount using M4x12mm Carriage Bolts (S-D), using 5mm Allen Wrench (T-C). Insert Pole Cap (G) into top of Pole (A). Place Cable Clips (M) onto M4 Nuts (S-C), and Wrench (T-A).
  • Page 5 OPTION #2 OPTION #3 Install Extension Brackets (H) onto your VESA mount using M4x12mm Carriage Bolts (S-D), Install Extension Brackets (H) onto your VESA mount using M4x12mm Carriage Bolts (S-D), M4 Nuts (S-C), and Wrench (T-A). M4 Nuts (S-A), and Wrench (T-A). Place extension bracket assembly over monitor.
  • Page 6: Cable Management

    STEP 5 CABLE MANAGEMENT Press Plastic Covers (J) over screw holes on “L” Support Holder (I). Route cables through Arm Cable Clips (M) and Pole Cable Clip (L). ADJUST AS DESIRED To level monitors, remove M6 Security Nuts (S-B) and tighten or loosen adjustment screws using 3mm Allen Wrench (T-B).
