4.1 Frequently used functions

Using the Smart Card Reader (SCR)
1. Insert the card firmly into the allocated slot with the chip facing towards the front of the terminal. (See
figure below). The Smart Card will be recognized by the terminal.
Using the RFID Reader
Present the card to the RFID readers by tapping and holding it briefly onto the clearly reader-marked area until the
card is read.

4.2 Power on, Reset and shut down

Power on:
The following methods are available to turn on the system.
1. Connect the 19V power supply to the DC jack, the system will boot up automatically.
2. Press the power button on the front of the Terminal while the power supply has been connected.
Reset:
1. Enter the OS, select restart and the system will reboot.
2. Press the reset button located at the . The system reset itself.
I/O recess
Shut down:
1. Enter the OS, select shutdown and the system will shut down.

4.3 The LED color definition

Green:
Back light powered on.
Orange:
Back light powered off (Stand-by mode).
