Quick Reference Guide

3.1 VESA Mounting (For VESA SKU)

Medi-View AID-185 also provides VESA mounting SKU to help system integrators conveniently integrate the
panel PC into their system.
Never use mounting brackets except as provided by Avalue to prevent unreliable mounting of the Medi-View
AID-185. VESA mount installation should be carried out by a professional technician; please contact a service
technician or your retailer if you need this service.
Installation instructions follow:
1. First attach the wall-mounting to the heat-sink of the Medi-View AID-185, securing it in place with four of the
M4 x 6mm screws provided.
2. Mount the system on the wall, stand or other flat surface.

3.2 Booting up the Medi-View

Connect the male plug of the power supply to an electrical outlet.
Switching on the power
Switch on the Medi-View via the power switch on the front cover (See figure below).
