RMW10

4. Operation

Receiver RMW10

A: Frequency group.
B: Channel.
C: Mute (symbol is displayed when function mute is activated).
D: Selected frequency.
E: Transmitter Battery charge level.
F: Audio in input level.
G: Level of the signal received.

Automatic scan

Pressing for one second MEM key, full band frequency receiver automatic scan is activated . During such scan, the audio is selected
and the current frequency is displayed . The scan is stopped when as soon as a signal is individuated, the relevant frequency value
then lights. Press MEM to memorise the frequency . To continue the scan press UP.
Manual frequency selection
Pressing MENU key the GROUP indicator lights, select the frequency group using keys UP and DO, memorise the selected GROUP
using MEM key.
Press two times MENU Key the CHANNEL indicator lights, choose the channel using UP and DO keys. Use MEM key to save the
selected GROUP.

Output level control

Select line level mode pressing 3 times Key MENU, The display indicates PL and the level current value:
0 = 500mV - 1 = 300mV - 2 = 150mV.
Select the level using keys UP and DN, confirm using MEM key.

Mute function

Press 4 times MENU key, MUTE symbol function lights, using key UP and DN to activate or disable such function. Confirm choice
pressing MEM key . When Mute function is active the is no audio signal in output.
MUTE FUNCTION OFF
20
MUTE FUNCTION ON
