4. Installation

4. Installation
The unit can be installed either on a wall or a stand pipe.
In order to do this an optional wall or stand pipe mounting
kit can be ordered and used. (See 13. Accessories and
consumables)

4.1 Wall mounting

(Wall mounting installation kit, order No. 50086642)
Open the unit cover and screw the unit to the mounting plate as
shown in the diagram.

4.2 Stand pipe mounting

(Stand pipe mounting installation kit, order No. RDL10A-MA)
Open the unit cover and screw the unit to the mounting plate as
shown in the diagram.
27
