6.

IR REMOTE CONTROL

The Matrix can be controlled by the provided IR Remote by pointing it directly at the IR sensor
on front panel. This allows for selecting inputs (source) for each output (display) as well as
power On and Off for connected CEC-enabled displays.
Click to Power Off CEC-Enabled
Display of Output 1
Click to Power On CEC-Enabled
Display of Output 1
Assigning Inputs (sources) to Outputs (display):
1. On the remote locate the output to assign an input to, these are in order vertically from
top to bottom labeled in the middle of the remote.
2. Press the desired Input # or use the Previous
available inputs.
Virtual IR Code Supported by Default (Matrix Switching Code)
Code Left (
Out1 0x57
Out2 0x1B
Out3 0x55
Out4 0x07
) Right ( ) In1
0x41 0x09
0x11 0x17
0x48 0x5E
0x40 0x18
Select Previous Input for Output1
Select Next Input for Output1
Select Specific Input for Output 1
or Next
In2
0x1D
0x12
0x06
0x44
12
button to scroll through the
In3 In4
0x1F 0x0D
0x59 0x08
0x05 0x03
0x0F 0x51
