1.
PRODUCT OVERVIEW
The B-660-MTRX-4x4 is a 4K HDR 4x4 HDMI Matrix Switcher and allows up to four Ultra
High Definition 4K HDR or 1080p HD inputs to be independently distributed to four Ultra
HD displays. Analog audio outputs are also included for 2ch PCM audio de-embedded from
each HDMI output allowing for audio to be distributed separately from each HDMI output.
This matrix is controllable via IR, RS-232 and LAN using the built in Web UI. An API is available
separately for RS-232 and LAN control.
This matrix was designed to be an Ultra HD A/V distribution solution ideal for a variety of
applications that include Home Theater, Offices, Schools, Conference Rooms, Hotels, etc. All
this contained in a compact chassis that occupies only 1U of rack mount space.
2.
FEATURES
• 4 HDMI inputs and 4 HDMI outputs
• Inputs and outputs support video resolutions up to 4K@60Hz 4:4:4 8bit and HDCP 2.2
• Supports 4K HDR, HLG & Dolby Vision™
• Fast switching between multiple video sources
• Supports L/R analog audio de-embedding outputs from each HDMI output (2ch PCM Audio
only)
• Supports IR, RS-232 and LAN (Telnet API & Web UI) control options
• Supports API command control through RS-232 and Telnet connection
3.
PACKAGE CONTENTS
• 1 x B-660-MTRX-4x4 Matrix
• 1 x AC Power Cord with US Pins
• 1 x IR Remote
• 2 x Mounting Brackets (with Screws)
• 1 x Installation Manual
8
