Viewing Network Connectivity

Path: Status > Connection
The Connection page shows information about the status of the cable modem's HFC and IP
network connectivity. This is the same information shown on the Login screen on page 35.
The information on this page is organized into the following sections:
Section
Startup Procedure Shows the procedures performed by the cable modem at startup, their status, and any comment associated
with the procedures.
Downstream Bonded Shows the channel, lock status, modulation, channel ID, frequency, power, signal-to-noise ratio (SNR), and
Channels total correctables and uncorrectables.
Upstream Bonded Shows the channel, lock status, upstream (US) channel type, channel ID, symbol rate, frequency, and power.
Channels
CM IP Address Shows the cable modem IP address, its duration and the date and time when it expires.
Frequency Select Lets you enter the frequency, in MHz, to be used for communications over downstream channel 1 (DS1).
(DS1) Click TUNE to apply your setting.
Current System Time Shows the current date and time.
