PICO50R/PICO51R Pico-ITX Board
2.3
Assembly Drawing
For thermal dissipation, a thermal solution enables the PICO50R/51R's components to
dissipate heat efficiently. All heat generating components are thermally conducted to the
heatspreader in order to avoid hot spots. Images below illustrate how to install the thermal
solution on PICO50R/51R.
Standard – Heatsink with fan for PICO50R/51R (see image below):
1.
Fan
cable
Please pay attention to the position of fan cable when assembling heatsink.
Note
10
Board and Pin Assignments
Fan
cable
