Connectors - AXIOMTEK PICO50R User Manual

PICO50R/PICO51R Pico-ITX Board
2.5

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table of connectors on the hardware.
Connector
CN1
CN2
CN3
CN4
CN5
CN6
CN7
CN8
CN9
CN10
CN11, CN12
CN13
CN14
BAT1
SCN2
SCN3, SCN4
SCN5
14
Description
DDR4 SO-DIMM Connector
Front Panel Connector
Inverter Connector
LVDS Connector
USB 2.0 Wafer Port 3 and 4
SMBus Connector
M.2 2242 Key B Connector
M.2 2230 Key E Connector
Power Connector
USB 3.0 Port 1 and 2
Ethernet Ports
DisplayPort Connector
Digital I/O Connector
CMOS Battery Connector
Fan Connector
COM2 and COM1 Wafer Connectors
Power Output Connector
Board and Pin Assignments
