Ethernet Ports (CN11 and CN12)

The board has two RJ-45 Ethernet connectors, CN12 for LAN1 with Intel
CN11 for LAN2 with Intel
one end of the Ethernet cable into this connector and the other end (phone jack) to a
1000/100/10-Base-T hub.
1000
Pin
Base-T
L1 BI_DA+
L2 BI_DA-
L3 BI_DB+
L4 BI_DC+
L5 BI_DC-
L6 BI_DB-
L7 BI_DD+
L8 BI_DD-
Active Link LED (Yellow)
A Off: No link
Blinking: Data activity detected
Speed LED
B 1000: Orange
100/10: Green/OFF
2.5.11

DisplayPort Connector (CN13)

The DisplayPort interface is available through connector CN13.
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
22
®
i211AT. Ethernet connection can be established by plugging
100/10
Description
Base-T
TX+ Bidirectional or Transmit Data+
TX- Bidirectional or Transmit Data-
RX+ Bidirectional or Receive Data+
N.C. Bidirectional or Not Connected
N.C. Bidirectional or Not Connected
RX- Bidirectional or Receive Data-
N.C. Bidirectional or Not Connected
N.C. Bidirectional or Not Connected
Signal
DPB_LANE0
GND
DPB_LANE0#
DPB_LANE1
GND
DPB_LANE1#
DPB_LANE2
GND
DPB_LANE2#
DPB_LANE3
GND
DPB_LANE3#
Detect Pin
GND
DPB_AUX
GND
DPB_AUX#
DPB_HPD
GND
+3.3V
®
i219LM and
A B
L8 L7 L6 L5 L4 L3 L2 L1
A B
Board and Pin Assignments
