Schematic, PCB Layout, and Bill of Materials
6.2
PCB Layout
Figure 3
through
Figure 9
Figure 3. INA281EVM Top Overlay
10
INA281EVM
illustrate the PCB layout for the INA281EVM.
Copyright © 2020, Texas Instruments Incorporated
Figure 4. INA281EVM Bottom Overlay
Submit Documentation Feedback
www.ti.com
SBOU244 – June 2020
