1.2 Name of each printer part

Screen
Z Leading Rod
Z Threaded Rod
X Limit Switch
X Motor
Extruder
Z Limit Switch
Mainboard
Z Left Motor

1.3 Assembly Step

Step 1
Please be aware the screw holes is in orange circles.
Item
1
2
3
4
5
40 Fan
50 Soprador
X Leading Rod
Extruder Motor
Power
Y Motor Step 2
Please be aware the screw holes is in orange circles.
Y Limit Switch
Item
1
Hotbed
2
Z Right Motor
3
4
Y Threaded Rod
Y Leading Rod
page 12
Name of parts QTY.
Bottom support plate 1
Top support plate 1
Side support plate 2
M3*18 Screw 12
M3 Nut 12
Before Assembly
Name of parts QTY.
Step 1 1
support plate lock plate 2
M3*18 Screw 4
M3 Nut 4
Before Assembly
M3
M3*18
Step 1
After Assembly
M3
M3*18
Step 2
After Assembly
