RM15000

Power
Switch
Handle
Power
Switch
Handle
Figure 80.
1. Disconnect the power cable from the failed power supply (LED is off).
2. Remove the mounting screw holding the power supply.
3. Grasp the handle and pull the power supply out.
4. Insert a replacement power supply.
5. Install the mounting screw to hold the power supply in place.
6. Connect the power cable to the replacement power supply.
This completes the power supply replacement procedure for RM15000.

RM4000

Shut down the UltraTrak RM4000 before beginning replacement
of the power supply.
.
1. Switch off the power to the UltraTrak.
2. Remove the power cable.
3. Turn the main power switch on and off once to discharge any residual
voltage.
4. Remove the nine screws attaching the back cover and remove the back
cover.
RM8000/SX8000 Power Supply
Chapter 10: UltraTrak Maintenance
Caution
155
LED
Mounting
Screw
LED
Mounting
Screw
