A.1

Introduction

The FPM-212/215/217 touchscreen uses advanced 5-wire resistive technology. It
features a more accurate sensing capacity than comparable technologies. The
touchscreen is designed for rugged industrial environments, and adheres to FCC
Class A standards.
A.2

Touchscreen Specifications (12"/15"/17")

A.2.1

Typical Optical Features

Specification
Light Transmission
Haze
A.2.2

Electrical Specifications

Specification
Operation Voltage
Contact Current
A.2.3

Environment Specifications

Specification
Operating Temperature
Storage Temperature
Humidity
A.3

Installing Drivers for Windows OS

This touchscreen features drivers for Windows 7/8/10 and ADV Linux users. The
FPM-212/215/217 series requires the installation of the Penmount 6000 driver.
Please check the website below to download the Penmount 6000 driver.
https://support.advantech.com/support/new_default.aspx
FPM-200 Series User Manual
12" 15"
Above 75% Above 75%
< 1% < 1%
12" 15"
5.5 V or below
5.5 V or below
70 mA (Maximum)
70 mA (Maximum)
12" 15"
0 ~ 50 °C (32 ~ 122 0 ~ 50 °C (32 ~ 122
°F) °F)
-20 ~ 60 °C (-4 ~ 140 -20 ~ 60 °C (-4 ~ 140
°F) °F)
10 ~ 95%, non-condensing
14
17"
Above 75%
< 1%
17"
5.5 V or below
70 mA (Maximum)
17"
0 ~ 50 °C (32 ~ 122
°F)
-20 ~ 60 °C (-4 ~ 140
°F)
