- Page 1 FPM-3190 Industrial Flat Panel Monitor with 19" LCD in VGA/Video User’s Manual...
- Page 2 Copyright This document is copyrighted by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements to the products described in this manual at any time. Spec- ifications are thus subject to change without notice.
- Page 3 FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence when the equipment is operated in a residential environment.
-
Page 4: Packing List
If any of these items are missing or damaged, contact your distributor or sales representative immediately. Additional Information and Assistance 1.Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. 2.Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. -
Page 5: Safety Instructions
Safety Instructions 1. Read these safety instructions carefully. 2. Keep this User's Manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4. For plug-in equipment, the power outlet socket must be located near the equip- ment and must be easily accessible. - Page 6 - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advan- tech disclaims all responsibility for the accuracy of any statements contained herein. FPM-3190 User’s Manual...
-
Page 7: Table Of Contents
Rack Mounting ............. 10 Figure 2.3:Rack Mounting..........10 Desktop, Swingarm mounting......... 11 2.2.1 Desktop Stand ............... 11 Figure 2.4:Desktop Stand for the FPM-3190 series ..11 2.2.2 Swing-ARM..............12 Figure 2.5:Swing-ARM for the FPM-3190 series ..12 Appendix A Touchscreen Driver Installation ....14 Introduction .............. - Page 8 FPM-3190 User’s Manual viii...
- Page 9 Introduction This chapter includes: • Introduction • Specifications • LCD Specification • Connectors • Dimensions...
-
Page 10: Chapter 1 Introduction
Chapter 1 Introduction 1.1 Introduction Advantech's FPM-3190 Series is a 19" color TFT LCD flat panel monitor built specifically for industrial applications. With the optional touch- screen, the FPM-3190 Series is an excellent and user-friendly system control interface. In addition to its usual application as an LCD panel monitor, the FPM-... -
Page 11: Lcd Specification
• Vibration (operating): 5 ~ 17 Hz, double-amplitude displacement 17 ~ 500 Hz, 1.0 G peak to peak • Dimensions: (W x H x D):482 x 399 x 66 mm (19" x 15.7" x 2.6") • Weight: 10 kg (22 lb) •... -
Page 12: Connectors
RS-232 port of the PC. The touchscreen cable is included with all orders which include the touchscreen option. DC 12 V Power in This connector will be connected to the DC 12V Switching Power Sup- ply. FPM-3190 User’s Manual... -
Page 13: Dimensions
1.5 Dimensions Figure 1.1: FPM-3190 Dimensions 444 x 377 mm (17.48" x 14.81") Chapter 1... - Page 14 FPM-3190 User’s Manual...
- Page 15 System Setup This chapter includes: •Mounting the Monitor - Wall/Panel/Rack Mounting - Desktop Stand/Swing-ARM Mounting...
-
Page 16: Chapter 2 System Setup
Chapter 2 System Setup 2.1 Mounting the Monitor The FPM-3190 Series can be placed as you require. The versatility of the FPM-3190 mounts enable it to be mounted on your desk or anywhere else. 2.1.1 Wall Mounting With wall brackets, the FPM-3190 can be mounted directly to a wall. -
Page 17: Panel Mounting
2.1.2 Panel Mounting If you need to install the FPM-3190 series on a panel mount, please release the mounting brackets by detaching four screws on rear side and fix them on up and bottom side by screws. Figure 2.2: Panel Mounting (cut out dimension: 444 mm x 377 mm) -
Page 18: Rack Mounting
2.1.3 Rack Mounting FPM-3190 series products could be directly mount to the industrial stan- dard 19" rack. There are four screw holes on each side of the panel. Figure 2.3: Rack Mounting FPM-3190 User’s Manual... -
Page 19: Desktop, Swingarm Mounting
2.2 Desktop, Swingarm mounting The FPM-3190 Series can be mounted in other ways. You can place the desktop stand for desktop use or attach it on a swing-arm bracket. 2.2.1 Desktop Stand The desktop stand bracket is attached to the rear of the FPM-3190. Sim- ply detach the small bracket at the top of the monitor by unscrewing the two screws. -
Page 20: Swing-Arm
2.2.2 Swing-ARM Detach the mounting brackets on the rear side, then attach the FPM-3190 series onto the Swing-ARM mount (75mm or 100mm square bracket). Figure 2.5: Swing-ARM for the FPM-3190 series FPM-3190 User’s Manual... -
Page 21: Touchscreen Driver
Touchscreen Driver Installation • Introduction • Specification • Installation... -
Page 22: Appendix A Touchscreen Driver Installation
Appendix A Touchscreen Driver Installa- tion A.1 Introduction The FPM-3190 Series’ optional touchscreen uses an advanced capacitive technology. It provides more accurate sensing capacity than other tech- nologies. The touchscreen is specially designed for tough industrial envi- ronments, and has been approved to FCC Class A and Class B standards. - Page 23 MIL-C-675C. Withstands 10,500 grams of force per Balance Beam Scrape Adhesion Mar Tester. MicroScratch tester with 10 micron radius tungsten carbide indenter takes a force of 1.8 Newtons. NEMA Rating: NEMA sealable. Gasketing: Complete water-resistant seal obtainable with polyethyl- ene gasket. Cleaning: Water, isopropyl alcohol, and similar non-abrasive cleaners.
-
Page 24: Installation Of Touchscreen Driver
A.3 Installation of Touchscreen Driver The touchscreen into the FPM-3190 Series provides drivers for use with MS-DOS, Windows 95, 98, NT, 2000 and XP. For the detail touchscreen drivers installation procedure, please refer \\FPM-3190TV\Touch- screen\TouchWare563. FPM-3190 User’s Manual... - Page 25 Supported Input Timing Modes...
-
Page 26: Appendix B Supported Input Timing Modes
49.500 #080 800 * 600 53.674 (+) 85.062 (+) 56.250 #081 1280 * 1024 63.981 (+) 60.02 (+) 108.000 #082 1280 * 1024 79.976 (+) 75.024 (+) 135.000 #083 1280 * 1024 91.146 (+) 85.024 (+) 157.500 FPM-3190 User’s Manual... - Page 27 OSD Operation Keypad...
-
Page 28: Appendix Cosd Operation Keypad
Note 2: If select auto setup is selected, please follow these procedure as below. 1. press the auto button 2. press the sel button, then select the save icon, save current status. 3. the auto setup procedure finish. FPM-3190 User’s Manual... -
Page 29: Osd Function
C.2 OSD Function Each selected value is stored into LCD memory after SEL signal input or time out. The stored values are not affected if the power is turned off. But the selected value is not available in case a selected mode is changed before time out or power is turned off before time out. - Page 30 YUV color: Press the < and > to select brightness, black level, con- trast, saturation, Hue, Flesh tone Save: The auto setup will not save the auto configuration when the Auto button is pressed. Only the save button will save auto config- uration status. FPM-3190 User’s Manual...
-
Page 31: Fpm-3190Tv Input Select Operation Process
C.2.2 FPM-3190TV Input select operation process Default setting for this devise is “Analog Source Input.” If you want to use other signal sources like DVI, Video, S-video. Please refer to the fol- lowing flow chart. Upon changing the signal input setting, the device will display what you select in the next boot up! Analog signal input connect On/Off... - Page 32 FPM-3190 User’s Manual...
