Page 1: User Manual
FPM-3150G Series 15" XGA TFT LCD Industrial Monitor with VGA and DVI Inputs User Manual... -
Page 2: Copyright Notice
Copyright Notice This document is copyrighted by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements to the products described in this manual at any time. Specifications are thus subject to change without notice. - Page 3 Product Warranty (2 years) Advantech warrants to you, the original purchaser, that each of its prod- ucts will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or...
- Page 4 FCC Class B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence when the equipment is operated in a residential environment.
- Page 5 If any of these items are missing or damaged, contact your distributor or sales representative immediately. Additional Information and Assistance Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
- Page 6 Safety Instructions Read these safety instructions carefully. Keep this User's Manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for clean- ing. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
- Page 7 The sound pressure level at the operator's position according to IEC 704- 1:1982 is no more than 70dB(A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. Wichtige Sicherheishinweise Bitte lesen sie Sich diese Hinweise sorgfältig durch.
- Page 8 IEC-704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. FPM-3150 Series User Manual...
-
Page 9: Table Of Contents
Contents Chapter 1 Introduction ............. 2 Introduction ............... 2 Specifications ..............2 LCD Specification............. 3 Power Consumption ............3 Connectors................. 4 Dimensions................ 5 Figure 1.1:FPM-3150G Dimensions ......5 Chapter 2 Mounting............8 Mounting the Monitor ............8 2.1.1 Wall Mounting ............... 8 Figure 2.1:Wallmounting .......... - Page 10 C.2.10 Mode Information Menu ..........31 C.2.11 Memory Recall Menu ..........32 C.2.12 Exit Menu ..............33 C.2.13 Hot Keys ..............34 FPM-3150 User Manual...
- Page 11 Introduction This chapter includes: • Introduction • Specifications • LCD Specification • Power Consumption • Connectors • Dimensions...
-
Page 12: Chapter 1 Introduction
Chapter 1 Introduction 1.1 Introduction Advantech's FPM-3150G is a 15" color TFT LCD flat panel monitor built specifically for industrial applications. With the optional touchscreen, FPM-3150G is an excellent and user-friendly system control interface. In addition to its usual application as an LCD panel monitor, FPM-3150G comes standard with direct VGA control signal input, making it compati- ble with Industrial PCs and Workstations. -
Page 13: Lcd Specification
Touchscreen (Optional) • Type: 8 wire, analog resistive • Resolution: 1024 x 1024 • Light Transmission: >80% (Gouge Hardness is greater tahn 4H per ASTM D3363-92 for HCC01, HCG10 and HCG12 • Operating Pressure: 30 ~ 45 gram for stylus pen contact bounce <... -
Page 14: Connectors
1.5 Connectors The following connectors are situated on the left hand side of the FPM-3150G Series: VGA Port (DB-15) This DB-15 connector can be connected to the system via the external 15-pin DB-15 connector locatd on the left side of the system unit. -
Page 15: Dimensions
1.6 Dimensions Figure 1.1: FPM-3150G Dimensions Chapter 1... - Page 16 FPM-3150 Series User Manual...
- Page 17 Mounting • Wallmounting • Panel Mounting • Rack Mounting • Desktop Mounting • Swing Arm Mounting...
-
Page 18: Chapter 2 Mounting
Chapter 2 Mounting 2.1 Mounting the Monitor The FPM-3150G Series can be mounted in many different ways. The versatility of the FPM-3150G mounts enable it to be mounted on your desk or anywhere else. 2.1.1 Wall Mounting FPM-3150G can be mounted directly on a wall with panel mounting brackets. -
Page 19: Panel Mounting
2.1.2 Panel Mounting If you need to install the FPM-3150G series in a panel, please release the mounting brackets by detaching four screws on rear side and fix them on the top and bottom with screws. Panel Mounting Brackets Figure 2.2: Panel Mounting (396 x 296 mm) -
Page 20: Rack Mounting (Optional)
2.1.3 Rack Mounting (Optional) If you need to install the FPM-3150G on a rack, you must order the rack mount kit for FPM-3150G (Part Number is FPM-3150G-RMKE). Attach the two rack mounting brackets on each side of FPM-3150G with 12 screws, then affix the monitor in the rack. -
Page 21: Desktop, Swing-Arm For Fpm-3150G
2.2 Desktop, Swing-ARM for FPM-3150G The FPM-3150G Series can be mounted in other ways. These is a desktop stand for desktop use and it can also be attached to a swing-arm bracket. 2.2.1 Desktop Stand The panel-mount bracket is attached to the rear of the FPM-3150G to become a desktop stand. -
Page 22: Swing-Arm (Vesa Compliant)
2.2.2 Swing-ARM (VESA Compliant) FPM-3150G has been designed with support for the VESA Arm standard. Refer to figure 2.5. Detach the mounting brackets on the rear side, and attach the FPM-3150G onto the VESA ARM Mount. Figure 2.5: Swing-ARM for FPM-3150G FPM-3150 Series User Manual... - Page 23 Touchscreen...
-
Page 24: A.1 Introduction
Appendix A Touchscreen A.1 Introduction The FPM-3150G Series optional touchscreen uses advanced 8-wire resis- tive technology. It provides more accurate sensing capacity than other technologies. The touchscreen is specially designed for tough industrial environments, and has been approved to FCC Class B standards. - Page 25 4. Linearity 4.1 Linear Test Specifications Direction X: <1.5 % Direction Y: <1.5 % 4.2 Linearity Test Apply voltage (DC5V) to upper (or lower ) electrodes, output voltage Vx or Vy on the other electrodes is measured at every regular intervals. Linearity is the value of max.
-
Page 26: Installing Driver For Windows Os
A.3 Installing Driver for Windows OS The touchscreen has drivers for Windows 2000 /XP/2003/Vista. You should read the instructions in CD-ROM Disk Touchscreen section care- fully before you attempt installation. The FPM-3150G-XCE, RCE need to install Penmount 6000 driver. Please find Penmount 6000 folder and install the driver into your system. - Page 27 Setting Serial Data for Expansion...
-
Page 28: Appendix B Setting Serial Data For Expansion
Appendix B Setting Serial Data for Expansion B.1 Setting Serial Data for Expansion The twelve kinds of timings below are already programmed in this mod- ule. The input synchronous signals are automatically recognized. Resolution Vertical Frequencies 56 Hz 60 Hz 70 Hz 72 Hz 75 Hz... - Page 29 OSD Operation Keypad...
-
Page 30: Appendix Cosd Operation Keypad
Appendix C OSD Operation Keypad C.1 OSD Board Overview The OSD keypad, including six keys and a two color indicator, is designed as the OSD operation interface C.1.1 OSD Button Description Buttons Descriptions Power Turn the monitor power ON or OFF. Auto/Exit Automatically adjust the clock, phase, H-position and V-position. -
Page 31: Osd Key Functions
C.2 OSD Key Functions Each selected value is stored into LCD memory after SEL signal input or time out. The stored values are not affected if the power is turned off. But the selected value is not available in case a selected mode is changed before time out or power is turned off before time out. -
Page 32: Input Source Select
C.2.2 Input Source Select • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation • Main Menu -- DISPLAY IN SCREEN • Sub-Menu – DISPLAY IN SCREEN • Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected... -
Page 33: Contrast/ Brightness Setting
Auto Select Input • ON start from default setting and scan the inputs by following sequence from ANALOG INPUT, DIGITAL INPUT, S-VIDEO INPUT, and CVBS INPUT. • OFF start from default setting C.2.3 Contrast/ Brightness Setting • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation... -
Page 34: Geometry Menu - For Dvi Input
• Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. RECALL VALUE – User Define • Rec1 Pressed to record 1 setting as recall value followed by current screen setting •... - Page 35 • Available Key Functions Power Off the Increase the gauge value LCD Monitor of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. Appendix C...
-
Page 36: Color Temperature Menu
C.2.5 Color Temperature Menu • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation • Main Menu -- DISPLAY IN SCREEN • Sub-Menu – DISPLAY IN SCREEN • Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected... -
Page 37: Rgb Color Menu
C.2.6 RGB Color Menu • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation Select by Left and Right Button, Press Menu Button for selection confirmation • Main Menu -- DISPLAY IN SCREEN • Sub-Menu – DISPLAY IN SCREEN •... -
Page 38: Language Menu
• Available Key Functions Power Off the Increase the gauge value LCD Monitor of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. Customization setting for RGB colors C.2.7 Language Menu •... -
Page 39: Osd Manager
• Available Key Functions Power Off the Increase the gauge value LCD Monitor of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. C.2.8 OSD Manager • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation •... -
Page 40: Auto Configuration Menu
• Available Key Functions Power Off the Increase the gauge value LCD Monitor of the selected option. Return to last Selected to confirm menu Decrease the gauge value of the selected option. C.2.9 Auto Configuration Menu • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation... -
Page 41: Mode Information Menu
• Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. Auto configuration can be set in menu and also can press the without any menu indication. -
Page 42: Memory Recall Menu
• Available Key Functions Power Off the Increase the gauge value LCD Monitor of the selected option. Return to last Selected to confirm menu Decrease the gauge value of the selected option. C.2.11 Memory Recall Menu • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation... -
Page 43: Exit Menu
• Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. C.2.12 Exit Menu • Generate Main Menu Select by Left and Right Button, press Menu Button for selection confirmation •... -
Page 44: Hot Keys
• Available Key Functions Power Off the Increase the gauge LCD Monitor value of the selected option. Return to last menu Selected to confirm Decrease the gauge value of the selected option. C.2.13 Hot Keys OSD LOCK/UNLOCK HOT KEYS Press first then press for change this setting, Followed this sequence for the button press so that you can have OSD LOCK and... - Page 45 • Entry OSD UNLOCK MODE • Press HOT KEY, the screen will show this action first • Don’t remove the HOT KEY until the screen indicated this task is fin- ished. Appendix C...
- Page 46 FPM-3150 Series User Manual...
