LCD Specification

Specifications
Display Type
Display Size
Max. Colors
Resolution
View Angle (H/V°)
Luminance
Storage Temperature
Operating Temperature
Contrast Ratio
Backlight Life
1.4

Connectors

The following connectors are situated on the bottom of FPM-212/215/217:
DP or HDMI port

DP or HDMI port are connected with a standard DP or HDMI connector through
unit I/O port located on the bottom side of the system.
VGA Port (DB-15)

DB-15 connector can be connected to the system via the external 15-pin DB-15
connector located on the bottom side of the system.
Touchscreen Connector (USB)

This connector will be present only if the touchscreen is installed. It must be
connected to the PC's USB port. A touchscreen cable is included with all orders.
DC 12 V Power Input Connector

This connector must be connected to 12 Vdc power supply.
Warning! Please note before connecting the monitor and PC with a HDMI / DP or
VGA cable:
1.
2.
12" LCD
(LED Backlight)
XGA TFT LCD
12"
16.2M Max
1024 x 768
178°(V), 178°(H)
2
600 cd/m
-20 ~ 60 °C(-4 ~ 140
°F)
0 ~ 50 °C (32 ~ 122
°F)
1000:1
50,000 hr
If the PC has an installed operation system, please confirm its por-
trait frequency within an acceptable range.
If the PC has an installed operation system, users need to adjust
the portrait frequency within an acceptable range.
15" LCD
(LED Backlight)
XGA TFT LCD
15"
16.2M Max
1024 x 768
176°(V), 176°(H)
2
300 cd/m
-20 ~ 60 °C (-4 ~
140 °F)
0 ~ 50 °C (32 ~ 122
°F)
2000:1
50,000 hr
3 FPM-200 Series User Manual
17" LCD
(LED Backlight)
SXGA TFT LCD
17"
16.7M Max
1280 x 1024
170°(V), 170°(H)
2
250 cd/m
-20 ~ 60 °C(-4 ~
140 °F)
0 ~ 50 °C (32 ~ 122
°F)
1000:1
30,000 hr
