Installation Instructions
Solenoid Valve S07-072 (closed body) and S07-072A (thru body)
8
7
8
9
Figure 13
Bradley Corporation • 215-1510 Rev. D; ECN 07-815
Express® Lavatory System - MG Series with Battery Infrared Control
6
5
SOLENOID VALVE W/CIRCUIT BOARD
CLOSED BODY
(S07-082)
4
THRU BODY
(S07-082A)
CIRCUIT BOARD
3
PAN-HEAD SCREW
2
1
REF. QTY. PART NO.
1 1 118-307
1
1 118-307A
2 1 269-983
3 1 192-017
4 1 135-093
5 1 269-1729
6 1 269-1730
7 1 269-1731
8 3 160-447
9 1 125-165
(S83-178)
6-19 x 3/4"
(160-451)
DESCRIPTION
VALVE BODY, 1/4" CLOSED
VALVE BODY, 1/4" THRU
DIAPHRAGM
ARMATURE
SPRING
ARMATURE HOUSING
CLAMP, ARMATURE HOUSING
COIL, SOLENOID VALVE
SCREW, #8 X 5/8
O-RING, #2-013
VALVE ASSEMBLY
CLOSED BODY
(S07-072)
THRU BODY
(S07-072A)
8/23/07
MG-2/BIR3
17
