able to leave the bearings in the alcohol for a lo�er time, an in­
hibited alcohol such as is used for anit- freeze should be used.
then the bearings should be removed from the alcohol within twenty­
four hours. Esso Anti-Freeze and
this purpose. Precautions against the toxic effects of the alcohol
must be exercised by wearing rubber gloves and by using the alcohol
in a well ventilated room; excessive exposure to the fumes is some­
times unpleasant to personnel.
oil and draining should follow immediately, then apply the lubricant.
The hinge of the primary contact arm {16) Fig. 7 should be disassembled
cleaned, and lubricated with G. E. D 50H47 lubricant at general overhaul
periods. A thin film of G.E. D50H47 should also be applied to the
silvered area of the primary contact arm where it enters the primary
fingers {5) Fig. 7, and the arcing contact blade where it enters the
arcing contact fingers {6) Fig. 7.
NOTE: not grease auxiliary blade (7) Fig. 7.
Do
DESCRIPTION OF OPERATION SE- lOOM
The SE- lOOM switch has a direct mechanical drive and the closing and
opening energy is supplied by the operator.
When operating the switch, the handle should be rotated with a posi­
tive motion throughout its entire stroke.
Closing the switch is accomplished by inserting the operating handle
{l) Fig. 3 into the handle socket provided in the operating hub {7)
Fig. 1 in the enclosure and rotating in a counterclockwise direction
as far as possible {approximately 180°) .
During the closing cycle the auxiliary blade (7) Fig.
out of the arc chute until the primary blades (ll) are almost closed.
Just before the primary contacts (5) Fig. 7 touch, the auxiliary blade
is released and will be the first part to close.
The mechanism has a direct gear drive to the main shaft of the switch
and depends entirely on the operator to produce a smooth and positive
motion to satisfactorily close.
To open the switch insert the operating handle into the handle socket
and rotate in a clockwise direction as far as possible {approximately
180 degrees) .
The primary contacts (5
mary blade gap is sufficient, the auxiliary blade (3) Fig. 4 will be
released and will snap open at high velocity.
Pont Zerone are satisfactory for
Du
Washing the bearings in the light
& 11)
Fig. 7 will part first.
GEI- 88767
Even
7
will be held
When the pri­
