ADJUSTMENTS SE-lOOM
Mechanism Stop
Refer to Page 6.
Primary Wipe
When the switch is in the closed position, there should be no clearance
between the primary blades and the primary finger support.
of the operating rod should be adjusted so that there is noticeable
force involved when the operating rod goes over center near the end of
the closing stroke.
between 30 and 40 pounds force to break the toggle.
plied at the bolt in the mechanism end of the operating rod and is ap-
plied downward perpendicular to the long axis of the operating rod.
force may be increased by lengthening the rod and decreased by shortening
the rod.
Primary Gap
Refer to Page 7.
Close the primary blades {12) Fig. 8
nance handle and note the engagement
guide block (10) .
out bearing heavily on either side.
the primary contact fingers.
If the blades press hard against the sides of the guide block, loosen
the {2) bolts {11) Fig. 8 holding the block.
alignment. If the contacts are properly aligned, reposition the guide
block and bolt securely.
If the contacts are not in alignment, loosen the bolts holding the
top insulator and position the insulator to center the contacts.
After securing the insulators, reposition the guide blocks and tighten
the bolts.
Be certain the insulator is moved only in a horizontal direction.
Vertical displacement may cause misalignment of the auxiliary blade
contacts.
Arc Chute Alignment
Refer to Page 7.
12
When the switch is fully closed it should require
The blades should
This force is ap-
slowly by the use of the mainte-
of the primary contacts {4) , and
center around the guide block with­
They should also be centered in
Again check the contact
The length
This
