Ergotron UKMCBK User Manual

Universal Keyboard & Mouse Caddy
Compact Keyboard & Mouse Caddy
Before beginning, please take a moment to review the parts
list to be sure your shipment is complete. Also, review the
instructions of all Anthro products you are planning to include in
this installation.
An electric drill and
assembly although some Anthro products are predrilled to
accept these caddies. A
cart) plus a Philips screwdriver & an adjustable wrench (not
included) are required for this assembly.

Component list for part # UKMCBK, 169BK

01– Wrist Rest ......................................Qty. 1 ............. 575-5001-01
02– Mouse Rail ....................................Qty. 1 ............. 575-5001-02
03– Mouse Pad ....................................Qty. 1 ............. 575-5001-03
04– Caddy Platform ...........................Qty. 1 ............. 575-5001-04
05– Acorn Nuts ..................................Qty. 4 ............. 325-5023-00
06– Wood Screws
3/4" (for UKMCBK) ......................Qty. 10 ..............325-5106-00
1/2" (for 169BK) ...........................Qty. 8.................325-5008-00
www.ergotron.com |
USA: 1-800-888-8458
• 08/19
300-5223-00 rev. F
1
/ " drill bit may be required for this
8
5
/ " Hex Driver, (provided with your
32
|
Europe: +31 (0)33-45 45 600
01
02
03
04
07– Rubber Bumpers ......................Qty. 2.................175-5130-03
08– Caddy Tray
For UKMCBK .................................Qty. 1.................225-5046-00
For 169BK ......................................Qty. 1.................575-5001-12
09– Caddy Mechanism
For UKMCBK .................................Qty. 1.................575-5001-09
For 169BK ......................................Qty. 1.................575-5001-13
10– Caddy Screws ..............................Qty. 4.................575-5001-10
11– Keyboard Pads ...........................Qty. 4.................575-5001-11
| |
