And Performance Report - UTC Fire and Security Det-Tronics Dual Spectrum PM-5MPX Instructions Manual

HAZARDOUS lOCATION RATINgS
• Intrinsically safe for Class I, II, III, Div. 1, Groups C, D, E, F and G Hazardous (Classified) Locations per FM 3610.
• Non-incendive for Class I, Div. 2, Groups A, B, C and D Hazardous (Classified) Locations per FM 3611.
AUTOmATIC FIRE AlARm SIgNAlINg pERFORmANCE (Fm 3260: 2000)
RESpONSE CHARACTERISTICS
(Typical Response Time < 0.5 Sec.)
Fuel Size
n-Heptane 1 x 1 foot
Isopropanol 8 in. dia.
Polypropylene 8 in. dia.
Note: Response time measurements based
upon shuttered test method.
FAlSE AlARm ImmUNITy
False Alarm Source
Arc welding, Type E6012 rod, 1/8" dia., 1/4" plate
70 W sodium vapor lamp
250 W mercury vapor lamp
300 W incandescent lamp
500 W quartz halogen lamp shielded w/window
1500 W electric quartz heater
Two 34 W fluorescent lamps
3.2
APPENDIX A
Fm Approvals Description and performance Report
Distance
(feet)
18
8
8
Distance
(inches)
42
6
12
8
30
108
<3
modulated Response
No alarm
No alarm
No alarm
No alarm
No alarm
No alarm
No alarm
8 8
Unmodulated Response
No alarm
No alarm
No alarm
No alarm
No alarm
No alarm
No alarm
95-8562 95-8562
