Setup and Operation (cont'd)
Punching with
1/2" (ø 0.885" [22.5 mm])
conduit size
Punching with
3/4" (ø 1.115" [28.3 mm])
to 2" (ø 2.416" [61.5 mm])
conduit sizes
Greenlee / A Textron Company
LS60L Battery-powered Punch Driver
Material
Being
Punched
1/2" (12.7 mm)
Pilot Hole
Punch
Material
Being
Punched
7/8" (22.2 mm)
Punch
Spacer Spacer
33967
3/4" Adapter
30043
3/8" Draw Stud
Die
Pilot Hole
Draw Stud
Die
9
4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
03248 03248
03248
Spacer
3/4"
