Capacity and Draw Stud Selection Guide

16 ga. (0.0598" [1.5 mm])
Mild Steel and 1/8" Soft Aluminum
10 ga. (0.1345" [3 mm])
Mild Steel
Stud and Accessories
1614SS 1924AA 33967
Draw Stud Spacer Adapter
29451
1924AA
7/16" Draw Stud
Spacer
1924AA 31872
Spacer 3/4" Draw Stud
31872
3/4" Draw Stud
33967
1924AA
Adapter
Spacer
Greenlee / A Textron Company
Standard and Slug-Buster Punches
1/2" 3/4" 1-7/32" 1"
con. con. con. con.
ø 0.885" ø 1.115" ø 1.210" ø 1.362" ø 1.701"
22.5 mm 28.3 mm 30.5 mm 34.6 mm 43.2 mm
LS60L Battery-powered Punch Driver
10 ga. (0.1345" [3 mm])
Stainless Steel
12 ga. (0.1046" [2.5 mm])
Stainless Steel
1-1/4" 1-1/2" 2" 1/2"
con. con. con. con.
ø 1.951" ø 2.416" ø 0.885" ø 1.115"
49.6 mm 61.5 mm 22.5 mm 28.3 mm
12
4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
Slug-Splitter
3/4" 1-7/32" 1" 1-1/4" 1-1/2"
con. con. con. con. con.
ø 1.210" ø 1.362" ø 1.701" ø 1.951"
30.5 mm 34.6 mm 43.2 mm 49.6 mm
2"
con.
ø 2.416"
61.5 mm
