Gastroback DESIGN MULTI JUICER DIGITAL Operating Instructions Manual page 46

remove excess fibre build up (from fruit or vegetables) according to the instructions ´Care
and Cleaning`.
B
C
D
Important: If the safety locking arm is not in the right position the motor will not start
moving and the display shows "Lockbar".
E
F
46
Align the arrows on the stainless steel filter basket with the arrows on
the motor drive coupling and push down until it clicks into place. Ensu-
re the stainless steel filter basket is fitted securely inside the integrated
pulp container and onto the motor base (picture B).
Step 3:
Place the juicer cover over the stainless steel filter on top of the filter
bowl surround (picture C). The feed chute has to be positioned in the
middle of the filter basket and the pulp spouting of the cover has to
face away from the interlocking safety arm.
Step 4:
Raise the safety locking arm straight up and lock into the two grooves
on either side of the juicer cover. The safety locking arm should now
be in a vertical position and locked into place on top of the juicer
cover (picture D).
Step 5:
Slide the food pusher down the feed chute by aligning the groove
of the food pusher with the small protrusion on the inside of the top
of the feed chute. Continue to slide the food pusher down the feed
chute (picture E).
Step 6:
G
Place the pulp container into position by tilting the motor
base slightly to the right. Insert the container under the jui-
cer cover on the left-hand side ensuring it is supported by
the container support extending from under the motor base (picture F).
