- Page 1 Quick Start Guide GV-IP Camera GV-EBD Series GV-ABL Series GV-ADR Series GV-AVD Series Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. UBN-QG-D...
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
-
Page 3: Table Of Contents
Contents Note for Installing Camera Outdoor ............... ii Note for Powering the Camera ................ii 1. GV-EBD Series ....................1 1.1 Packing List....................2 1.2 Overview ....................... 3 1.2.1 GV-EBD2702 / 4700 ....................3 1.2.2 GV-EBD4711 / 8711 ....................4 1.3 Installation..................... -
Page 4: Note For Installing Camera Outdoor
Note for Installing Camera Outdoor When installing the camera outdoor, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like. -
Page 5: Gv-Ebd Series
1. GV-EBD Series Camera Type Model No. GV-EBD2702 (IP67) GV-EBD4700 (IP67) Eyeball IP Dome GV-EBD4711 (IP67) GV-EBD8711 (IP67) -
Page 6: Packing List
1.1 Packing List H.265 Target Eyeball Dome Screw x 3 Screw Anchor x 3 Drill Template Paster Waterproof Rubber Set Download Guide Warranty Card ... -
Page 7: Overview
GV-EBD Series 1.2 Overview 1.2.1 GV-EBD2702 / 4700 Description Bottom ring Housing Lens Infrared indicator Power connector (DC 12 V) Ethernet connector / PoE... -
Page 8: Gv-Ebd4711 / 8711
1.2.2 GV-EBD4711 / 8711 Description Bottom ring Housing Microphone Lens Power connector (DC 12 V) Ethernet connector / PoE Micro SD card slot and default button compartment Default button Micro SD card slot... -
Page 9: Installation
GV-EBD Series 1.3 Installation The Target Eyeball Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Or you can purchase optional mounting accessories to mount the dome on a wall. Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount: Concealed Installation and Open Installation. - Page 10 3. Remove the bottom ring by turning it anticlockwise. Bottom Ring 4. Connect the cables and secure the camera. 5. Adjust the monitoring direction.
- Page 11 GV-EBD Series 6. Mount the bottom ring. For Open Installation Lead the cables out from the open slot on the bottom ring before screwing the camera to the ceiling as shown in step 4 of Conceal Installation.
-
Page 12: Gv-Ebd4711 / 8711 Installation
1.3.2 GV-EBD4711 / 8711 Installation For Concealed Installation Stick the drill template paster to the ceiling and drill three holes according to the drill template. Insert the screw anchors. ... - Page 13 GV-EBD Series Loosen the fixing screw and remove the housing by turning it to the position as shown. Secure the bottom ring to the ceiling with 3 supplied screws and connect the cable. Mount the housing by adjusting to the position as shown and press and turn to...
- Page 14 Adjust the monitoring direction. Then tighten the screw. For Open Installation Lead the cables out from the open slot on the bottom ring before screwing the camera to the ceiling as shown in step 5 of Concealed Installation. Note: You can optionally purchase GV-Mount211 or GV-Mount212 for Wall Bracket Mount.
-
Page 15: Gv-Abl Series
2. GV-ABL Series Camera Type Model No. GV-ABL2701 Series (IP66) GV-ABL2702 (IP67 + IK10) Bullet IP Camera GV-ABL4701 Series (IP66) GV-ABL4712 (IP67) GV-ABL8712 (IP67 + IK10) -
Page 16: Packing List
2.1 Packing List Bullet IP Camera Waterproof Rubber Set Screw Kit Drill Template Paster Download Guide Warranty Card ... -
Page 17: Overview
GV-ABL Series 2.2 Overview 2.2.1 GV-ABL2701 Series / 4701 Series Description Power connector (DC 12 V) Ethernet connector / PoE... -
Page 18: Gv-Abl2702 / 4712 / 8712
2.2.2 GV-ABL2702 / 4712 / 8712 Description Power connector (DC 12 V) Audio input / Audio output / GND Alarm input (IN, GND) / Alarm output (N,P) Ethernet connector / PoE Video Output (GV-ABL8712 Only) -
Page 19: Installation
GV-ABL Series 2.3 Installation The Bullet IP Camera is designed for outdoors. With the standard package, you can install the camera on the wall or ceiling. Or, you can purchase optional mounting accessories to mount your camera on a wall. Below are the instructions for Wall Mount. - Page 20 Drill four 30-mm deep holes according to the drill template. Insert the screw anchors. Screw the locknut and loosen the universal joint before attaching the camera to the wall.
- Page 21 GV-ABL Series Secure the camera to the wall and connect all cables. Adjust the monitoring direction. For Open Installation Lead the cables out from the open slot on the base before screwing the camera to the wall as shown in step 6 in For Concealed Installation. Note: You can optionally purchase GV-Mount502 for Wall Bracket Mount.
-
Page 22: Gv-Adr Series
3. GV-ADR Series Camera Type Model No. GV-ADR2701 (IP66) Mini Fixed Rugged IP Dome GV-ADR4701 (IP66 + IK10) -
Page 23: Packing List
GV-ADR Series 3.1 Packing List GV-ADR2701 / 4701 IR Mini Fixed Rugged Waterproof Rubber Set IP Dome Screw Kit Drill Template Paster Download Guide Warranty Card ... -
Page 24: Overview
3.2 Overview Description Ethernet connector / PoE Power connector (DC 12 V) Transparent Dome Cover... -
Page 25: Installation
GV-ADR Series 3.3 Installation The IR Mini Fixed Rugged IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount: Concealed Installation and Open Installation. - Page 26 Unscrew the transparent dome cover with the supplied torx wrench. Connect the cables and secure the camera. Adjust the monitoring direction and tighten the screws after vertically adjusting the lens.
- Page 27 GV-ADR Series Secure the transparent dome cover with the supplied torx wrench. Note: Before securing the transparent dome cover, make sure the waterproof rubber strip is tightly held by the six retainers on the bottom ring. For Open Installation Lead the cables out from the open slot on the camera base before screwing the camera to the ceiling as shown in step 4 in For Concealed Installation.
-
Page 28: Gv-Avd Series
4. GV-AVD Series Camera Name Model No. GV-AVD2700 (IP67 + IK10) Vandal Proof IP Dome GV-AVD4710 (IP67 + IK10) GV-AVD8710 (IP67 + IK10) -
Page 29: Packing List
GV-AVD Series 4.1 Packing List IR Vandal Proof IP Dome Waterproof Rubber Set Screw Kit Drill Template Paster Torx Wrench Download Guide Warranty Card ... -
Page 30: Overview
4.2 Overview Description Power connector (DC 12 V) Ethernet connector / PoE Video Output Audio input / Audio output / GND Alarm input (IN,GND) / Alarm output (N,P) Default button Micro SD card slot... -
Page 31: Installation
GV-AVD Series 4.3 Installation The Target Vandal Proof Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Alternatively you can purchase optional mounting accessories to mount the camera on a wall. Below are the instructions for Ceiling Mount. There are two kinds of Ceiling Mount: Concealed Installation and Open Installation. - Page 32 4. Connect the camera cables and secure the camera. 5. Insert a SD card into the slot. 6. Adjust the monitoring direction and tighten the screws after vertically adjusting the lens. 7. Secure the transparent dome cover with the supplied torx wrench. For Open Installation Lead the cables out from the open slot on the camera base before screwing the camera to the ceiling as shown in Step 4.
-
Page 33: Waterproofing The Cable
5. Waterproofing the Cable Waterproof the Ethernet cable by using the supplied waterproof rubber set. Attach the seal ring to the RJ-45 plug. Seal ring Insert the waterproof components through the Ethernet cable as shown below. 2 Insert in order Insert the cylindrical waterproof ring into waterproof bolt. Cylindrical waterproof ring Waterproofbolt... - Page 34 Insert the cable into the RJ-45 plug and screw the waterproof bolt in. Screw in the waterproof bolt lid. Bolt lid Finish the waterproof installation.
-
Page 35: Accessing The Camera
6. Accessing the Camera 6.1 System Requirements Once installed, your camera is accessible over the network. Make sure your PC has good network connection and meet the following requirements: Intel Core i5-4670, 3.40 GHz Memory DDR3 8 GB RAM On Board Graphics Intel HD Graphics 4600 (Versions of driver from year 2014 or later required) Web Browsers... -
Page 36: Looking Up The Dynamic Ip Address
6.2 Looking Up the Dynamic IP Address By default, when the camera is connected to LAN a with DHCP server, it is automatically assigned with a dynamic IP address. Follow the steps below to look up its IP address. Note: The computer you use to configure the IP address must be under the same LAN as your camera. - Page 37 Accessing the Camera 4. The login page appears. 5. For first-time accessing of the Web interface, download and install the plug-in. 6. Type the default ID and password admin and click Login.
-
Page 38: Configuring The Ip Address
6.3 Configuring the IP Address If the camera is connected to a LAN without DHCP server, the default IP address will be 192.168.0.10. Follow the steps below to modify the IP address to avoid IP conflict with other GV-IP devices on the same LAN. 1. -
Page 39: The Web Interface
7. The Web Interface Once you log in the Web interface, you will see the live view as shown below. 10 11 12 13 14 15 No. Name Function Set the display ratio of the image. Scale: display images by 16:9. Proportional ... - Page 40 Only for models with motorized varifocal lens, increase Zoom +/- or decrease the camera’s optical zoom. Only for models with motorized varifocal lens, increase Focus +/- or decrease the camera focus. Play/Stop Play or stop live video. Only for audio-supporting models, adjust the audio output Video Volume volume on the PC.
-
Page 41: Upgrading System Firmware
8. Upgrading System Firmware GeoVision periodically releases updated firmware on the company website. To load the new firmware into the camera, follow the instructions below. 1. At the top of the Web interface, click Setup. 2. In the left menu, select System and select Maintenance. This page appears. -
Page 42: Restoring To Factory Default
9. Restoring to Factory Default If for any reason the camera is not responding correctly, you can restore the camera back to its factory default settings using the Web interface or the Default Button. Note: Only GV-EBD4711 / 8711 and GV-AVD2700 / 4710 / 8710 support a default button.
