GV-A/T/EBD Series IP Camera Mount
GV-Mount107
GV-Mount211-12
GV-Mount211P
GV-Mount213
GV-Mount300-2 / 310-2
GV-Mount312
GV-Mount420
GV-Mount440
GV-Mount504
GV-Mount511
GV-Mount924
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
Installation Guide
MT-ATEBDSERIES-C
Advertisement
Table of Contents
Related Manuals for GeoVision GV-A Series
Summary of Contents for GeoVision GV-A Series
- Page 1 GV-A/T/EBD Series IP Camera Mount Installation Guide GV-Mount107 GV-Mount211-12 GV-Mount211P GV-Mount213 GV-Mount300-2 / 310-2 GV-Mount312 GV-Mount420 GV-Mount440 GV-Mount504 GV-Mount511 GV-Mount924 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. MT-ATEBDSERIES-C...
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
-
Page 3: Table Of Contents
Contents Preface ........................1 Chapter 1 Installing Multi-Sensor Camera ..............2 1.1 Pendant Mounting ......................2 1.2 Wall Mounting ......................... 5 1.3 Corner Mounting ......................7 1.4 Pole Mounting ......................... 9 1.5 Wall Box Mounting ......................11 Chapter 2 Installing Eyeball Dome / Vandal Proof Dome ..........13 2.1 Pendant Mounting ...................... -
Page 4: Preface
Preface Welcome to the GV-A/T/EBD Series IP Camera Mount Installation Guide. This Installation Guide is designed for the following models: Model Model Number Bullet IP Camera GV-TBL2718 Multi-Sensor IP Camera GV-TMS8800 GV-EBDP5800 / 8800 Panoramic IP Camera GV-TBLP5800 / 8800 Vandal Proof IP Camera GV-TVD2712... -
Page 5: Chapter 1 Installing Multi-Sensor Camera
Chapter 1 Installing Multi-Sensor Camera 1.1 Pendant Mounting The mounting requires GV-Mount107 and Mount 511. GV-Mount107 GV-Mount511 GV-Mount107 Packing List GV-Mount107 Pendant Mount Bracket Pendant Tube Tube Connector Torx Wrench Applicable Models: GV-TMS8800 Note: Before installing GV-Mount107, note the following: ... - Page 6 GV-Mount107 + GV-Mount511 Installation Place GV-Mount107 on the ceiling and mark the location for the center socket and the 3 screws. Drill the marks and secure the Pendant Bracket onto the ceiling. Attach one end of the Pendant Tube to the Pendant Bracket, and the other end to the Tube Connector.
- Page 7 Fix the camera base to GV-Mount511, adjust the lens angle, and fix the housing to the camera base. Caution: Do not pull hard when leading the tail cables; otherwise, it will cause loose or disconnected tail cables.
-
Page 8: Wall Mounting
1.2 Wall Mounting The mounting requires GV-Mount211-12. GV-Mount211-12 GV-Mount211-12 Packing List GV-Mount211-12 Long Screw (47 mm) x 5 Short Screw (10 mm) x 4 Screw Anchor x 5 Drill Template Paster Applicable Models: GV-TMS8800 GV-Mount211-12 Installation Unscrew the bottom of GV-Mount211-12 to separate the two parts. Drill 4 mounting holes on the wall using the drill template paster. - Page 9 Secure the camera bottom onto the upper part of GV-Mount211-12 using the supplied short screws as indicated below. Fix the housing to the camera base and assemble GV-Mount211-12 to complete the installation.
-
Page 10: Corner Mounting
1.3 Corner Mounting The mounting requires GV-Mount211-12 + GV-Mount312. GV-Mount312 Packing List GV-Mount312 M4 Screw (20 mm) x 4 M8 Screw (80 mm) x 4 Applicable Models: GV-TMS8800 Note: GV-Mount312 must be used in conjunction with GV-Mount211-12. GV-Mount211-12 + GV-Mount312 Installation Drill 4 mounting holes on the corner using the drill template paster. - Page 11 Secure the bottom of GV-Mount211-12 onto GV-Mount312 using the supplied screws as indicated below. Note: Make sure the direction of the UP indicators on the 2 parts are placed pointing upward. Follow Step 4 ~ 7 in 2. Wall Mounting with GV-Mount211-12 to complete the installation.
-
Page 12: Pole Mounting
1.4 Pole Mounting The mounting requires GV-Mount211-12 + GV-Mount420. GV-Mount420 Packing List GV-Mount420 M4 Screw x 4 Additional Screw Kit M6 Screw x 4 M6 Nut x 4 M6 Plain Washer x 4 M6 Split Washer x 4 Applicable Models: ... - Page 13 Align and attach the bottom of GV-Mount211-12 to GV-Mount420 using the supplied screws as indicated. Note: Make sure the direction of the UP indicators on the 2 parts are placed pointing upward. Thread the 3 steel straps onto the back plate. Follow Step 4 ~ 7 in 2.
-
Page 14: Wall Box Mounting
1.5 Wall Box Mounting The mounting requires GV-Mount511. GV-Mount511 Packing List GV-Mount511 M3 Screw (25 mm) x 4 M3 Screw (12 mm) x 2 Screw Anchor x 4 Drill Template Paster Applicable Models GV-TMS8800 GV-Mount511 Installation Drill 4 mounting holes and a hole at the center socket location on the wall using the drill template paster. - Page 15 Unscrew the four screws of the camera to remove the housing from the camera base. Cut open GV-Mount511 base and thread the camera cables through the center socket and waterproof the Ethernet cable. For details, see 1.10 Waterproofing the Cable in the User’s Manual.
-
Page 16: Chapter 2 Installing Eyeball Dome / Vandal Proof Dome
Chapter 2 Installing Eyeball Dome / Vandal Proof Dome 2.1 Pendant Mounting The mounting requires GV-Mount107 and GV-Mount213 / 212P. GV-Mount213 is for eyeball domes, while GV-Mount212P is for vandal proof domes. The following illustration uses GV-Mount213 as an example: GV-Mount107 Packing List Pendant Bracket Pendant Tube... - Page 17 Note: Before installing GV-Mount107, note the following: Install your camera on GV-Mount213 / 212P by cutting a hole in the center of the mount and thread the camera wires through. Prepare 3 long screws for securing the Pendant Bracket to the ceiling. ...
-
Page 18: Junction Box Mounting
2.2 Junction Box Mounting The mounting requires GV-Mount211P. GV-Mount211P GV-Mount211 GV-Mount211P Packing List GV-Mount211P Long Screw x 5 Short Screw x 4 Screw Anchor x 5 Plastic PG21 Conduit Connector Drill Template Paster Applicable Models: Eyeball Dome GV-EBD2702 / 2704 / 2705 / 4700 / 4701 / 4704 / 4711 / 4712 / 4813 / 8700 / 8711 / 8800 / 8813 ... - Page 19 GV-Mount2111P Installation Unscrew the bracket. Loosen the indicated area by turning it anticlockwise. Power Box Stick the drill template paster to the wall with the arrow pointing up. Drill 4 holes according to the sticker and insert the 4 screw anchors to the 4 holes. Secure the power box to the wall with 4 long screws.
- Page 20 Remove the bottom ring by turning it anticlockwise. Bottom Ring Secure the camera to the wall mount bracket with the provided short screws according to the screw position for each model: GV-EBDP5800 / 8800...
- Page 21 GV-EBD2702 / 2704 Thread the Ethernet cable through the PG21 conduit connector and the power box as shown in No. 8, Step 10. Then connect the cable to the camera. Rotate the plastic ring to secure the conduit connector to the power box. Screw in the cap as shown in No.
- Page 22 11. Mount the bottom ring.
-
Page 23: Convex / Concave Corner Mounting
2.3 Convex / Concave Corner Mounting The mounting requires GV-Mount211P and GV-Mount300-2 / 310-2. GV-Mount300-2 is for convex corner mounting, while GV-Mount310-2 is for concave corner installation. GV-Mount300-2 / 310-2 Packing List Mounting Bracket Convex / Concave Mounting Plate x 2 1/4”... - Page 24 Position and secure GV-Mount211P to GV-Mount300-2 / 310-2 as indicated below. Secure your camera to the GV-Mount211P to complete the installation.
-
Page 25: Pole Mounting
2.4 Pole Mounting The mounting requires GV-Mount211P and Mount420. GV-Mount420 Packing List GV-Mount420 M4 Screw x 4 Additional Screw Kit M6 Screw x 4 M6 Nut x 4 M6 Plain Washer x 4 M6 Split Washer x 4 Applicable Models: ... - Page 26 GV-Mount211P + Mount420 Installation Unscrew the bracket. Loosen the indicated area by turning it anticlockwise. Power Box Align and attach the power box to the back plate using the 4 supplied M4 screws as indicated. Note: Make sure the direction of the “up ↑” indicator on the back plate match that of the power box.
- Page 27 Thread the 3 steel straps onto the back plate. To install the camera to the GV-Mount211P junction box, follow Step 6 ~ 12 in 2.2 Junction Box Mounting. Secure the camera onto the desired pole by tightening the steel straps.
-
Page 28: Wall / Ceiling Box Mounting
2.5 Wall / Ceiling Box Mounting The mounting requires GV-Mount213 or GV-Mount211P. GV-Mount213 is for eyeball domes, while GV-Mount211P is for vandal proof domes. The following illustration uses GV-Mount213 as an example: GV-Mount213 / 212P Packing List GV-Mount213 / 212P Long Screw x 3 Short Screw x 3 Screw Anchor x 3... - Page 29 2. Drill 3 holes according to the screw locations. Then, drill a bigger hole at the center socket location for the Ethernet cable. 3. Insert 3 screw anchors to the screw locations and secure GV-Mount to the wall / ceiling with 3 long screws.
- Page 30 Note: In addition to the abovementioned standard installation, you can also choose to run the Ethernet cable through a corrugated tube. To do this, you will have to purchase your own conduit connector and corrugated tube. 3/4” NPS is the recommended type of connector.
-
Page 31: Power Box Mounting
2.6 Power Box Mounting The mounting requires GV-Mount924. GV-Mount924 Packing List GV-Mount924 M3 8 mm Screw x 4 Applicable Models GV-EBDP5800 / 8800 The mounting is only for eyeball domes. GV-Mount924 installation 1. Secure the gang box onto the back of GV-Mount924 using the ports indicated below. US Double Gang Box US Single Gang Box... - Page 32 2. Thread the camera’s cables through GV-Mount924 and secure the camera onto the mount using the ports indicated below using the supplied screws.
-
Page 33: Chapter 3 Installing Bullet Camera
Chapter 3 Installing Bullet Camera 3.1 Convex / Concave Corner Mounting The mounting requires GV-Mount504 and GV-Mount300-2 / 310-2. GV-Mount300-2 is for convex corner mounting, while GV-Mount310-2 is for concave corner installation. GV-Mount300-2 / 310-2 Packing List Mounting Bracket Convex / Concave Mounting Plate x 2 1/4”... - Page 34 GV-Mount300-2 / GV-Mount310-2 + GV-Mount504 Installation Follow the instructions in 3.2 Wall Box Mountin to install the camera onto GV-Mount504. Assemble the GV-Mount300-2 / 310-2, by attaching the two mounting plates onto the mounting bracket with the supplied carriage bolts, 1/4” plain washers, and 1/4” flange nuts.
-
Page 35: Wall Box Mounting
3.2 Wall Box Mounting The mounting requires GV-Mount504. GV-Mount504 Packing List GV-Mount504 Long Screw x 4 Short Screw x 3 Screw Anchor x 4 Drill Template Paster Waterproof Rubber Plug Plastic PG21 Conduit Connector Applicable Models: GV-TBL2718 GV-TBLP5800 / 8800... - Page 36 GV-Mount504 Installation 1. Unscrew the box cover. 2. Stick the drill template paster to the wall with the arrow pointing up. 3. Drill the 4 mounting holes according to the drill template. 4. Insert the 4 screw anchors to the mounting holes. 5.
- Page 37 7. Connect the Ethernet cable using one of the two methods: Thread the Ethernet cable through the center hole. Thread the Ethernet cable through the PG21 conduit connector and the power box as shown in No 8 in the figure below. Rotate the plastic ring to secure the conduit connector to the power box.
-
Page 38: Pole Mounting
3.3 Pole Mounting The mounting requires GV-Mount440 and GV-Mount504. GV-Mount440 Packing List GV-Mount440 M4 Screw x 4 Applicable Models: GV-TBL2718 GV-TBLP5800 / 8800 GV-Mount440 + GV-Mount504 Installation 1. Unscrew the box cover. - Page 39 2. Align and attach the power box to the back plate using the 4 supplied M4 screws as indicated. Note: Make sure the direction of the “up ↑” indicator on the back plate matches that of the power box. 3. Thread the 3 steel straps onto the back plate. 4.
-
Page 40: Power Box Mounting
3.4 Power Box Mounting The mounting requires GV-Mount924. GV-Mount924 Packing List GV-Mount924 M3 8 mm Screw x 4 Applicable Models GV-TBL2718 GV-TBLP5800 / 8800 GV-Mount924 installation 1. Secure the gang box onto the back of GV-Mount924 using the ports indicated below. US Double Gang Box US Single Gang Box... - Page 41 2. Thread the camera’s cables through GV-Mount924 and secure the camera onto the mount using the ports indicated below using the supplied screws.
