- Page 1 47699816001 Edition 1 September 2020 Compact Lift Air Chain Hoist Models CL125K, CL250K and CL500K Installation and Operation Information Installation and Operation Information Save These Instructions...
- Page 2 Only allow Ingersoll Rand trained technicians to perform maintenance on this product. For additional information contact Ingersoll Rand factory or nearest distributor. For additional supporting documentation refer to Table 1. Manuals can be downloaded from ingersollrand.com The use of other than genuine Ingersoll Rand replacement parts may result in safety hazards, decreased performance and increased maintenance and will invalidate all warranties.
-
Page 3: Installation
Installation Prior to installing the product, carefully inspect it for possible shipping damage. Hoists are supplied fully lubricated from the factory. Refer to “Lubrication” section for recommended oils and lubrication intervals. Lubrication of the load chain is recommended before initial hoist operation. Remove shipping lubrication plug and replace with breather. WARNING A falling load may result in death or serious injury. -
Page 4: Operation
Air Line Lubricator (standard) The use of an air line lubricator is required and it should be replenished daily and set to provide 2 to 3 drops per minute of IR #10 (10W non- detergent) tool oil. The lubricator must have an inlet and outlet at least as large as the inlet on the motor and capable of passing at least 150 percent of the hoist SCFM requirement. -
Page 5: Product Information Graphics
Product Information Graphics (Dwg. MHP0043) (Dwg. MHP0191) Throat Width Lower Raise (Dwg. MHP0040) (Dwg. MHP3111) (Dwg. MHP0111) Emergency Stop Lower Raise (Dwg. MHP0102) (Dwg. MHP3112) 47699816001_ed1 EN-4... - Page 6 Notes:...
- Page 7 Notes:...
- Page 8 ingersollrand.com © 2020 Ingersoll Rand...
