DEMO MANUAL DC1470A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 4 C1, C12, C16, C17
2 1 C2
3 1 C3
4 1 C4
5 6 C5, C6, C18, C21, C23, C25
6 1 C7
7 1 C8
8 2 C9,C10
9 1 C11
10 1 C15
11 1 C26
12 1 C27
13 1 D1
14 1 D2
15 1 L1
16 2 Q1,Q2
17 1 Q3
18 2 Q5,Q6
19 1 R1
20 1 R2
21 1 R3
22 7 R4, R9, R10, R12, R13, R14, R20
23 3 R5, R7, R8
24 1 R6
25 2 R15, R16
26 1 R18
27 1 R19
28 1 R23
29 1 R24
30 1 U1
Additional Demo Board Circuit Components
1 0 C13, C14, C19, C20, C22, C24
2 0 R11, R21, R22, R26
3 2 R17, R27
4 0 R25
5 0 Q4 OPT
Hardware for Demo Board Only
1 10 E1-E8, E13, E14
2 4 E9-E12
3 4 STAND-OFF
4
PART DESCRIPTION
CAP., X7R, 4.7μF, 50V, 10%, 1210
CAP., X7R, 1μF, 50V, 10%,0805
CAP., X7R, 0.22μF, 10V,10%,0603
CAP., X5R, 22μF, 6.3V, 20%, 0805
CAP., POSCAP, 470μF, 6.3V, D4D
CAP., C0G, 2nF, 50V, 0603
CAP., X7R, 1μF, 16V, 10%,0603
CAP., C0G, 5600pF, 50V, 5% 0603
CAP., ALUM., ELECT., 100μF, 50V
CAP., X5R, 0.033μF, 50V, 0603
CAP., X7R, 1200pF, 50V,5%, 0603
CAP., X7R, 10μF, 25V,10%,1206
SCHOTTKY RECTIFIER, 40V, SOD523
2.0A LOW VF SCHOTTKY RECTIFIER
INDUCTOR, 1.3μH
N-CHANNEL MOSFET, LFPAK
N-CHANNEL MOSFET, LFPAK
MOSFET, 40V, DUAL N-CHANEL, PPAK
RES., CHIP, 124k, 1%, 1/W, 0603
RES., CHIP, 374k, 1%, 1/W, 0603
RES., CHIP, 0.0025Ω, 1W, 1%, 2512
RES., CHIP, 100k, 1%, 1/W, 0603
RES., CHIP, 51k, 1%, 1/W, 0603
RES., CHIP, 10k, 1%, 1/W, 0603
RES., CHIP, 10Ω, 1%, 1/W, 0603
RES., CHIP, 24.9k, 1%, 1/W, 0603
RES., CHIP, 432k, 1%, 1/W, 0603
RES., CHIP, 3.01k, 1%, 1/W, 0603
RES., CHIP, 2k, 1%, 1/W, 0603
I.C. LT3743EUFD, 28-PIN QFN-4×5
CAP., D4D, OPT
RES., OPT, 0603
RES., CHIP, 0Ω, 0603
RES., CHIP, 2512, OPT
TURRET, TESTPOINT, 091"
JACK BANANA
STAND-OFF, NYLON 0.5" TALL
MANUFACTURER/PART NUMBER
MURATA, GRM32ER71H475KA88L
MURATA, GRM21BR71H105KA12L
MURATA, GRM188R71A224KA01D
MURATA, GRM21BR60J226ME39L
PANSONIC, 6TPF470MAH
MURATA, GRM1885C1H202JA01
MURATA, GRM188R71C105KA12D
MURATA, GRM1885C1H562JA01D
SUN ELECTRONICS., 50CE100LX
AVX, 06035D333KAT2A
AVX, 06035C122JAT2A
MURATA, GRM31CR71E106KA12L
NXP SEMI., PMEG4002EB,115
DIODES INC., DFLS240L-7
WURTH ELECTRONICS, 7443551130
INFINEON, BSC080N03LS G
INFINEON, BSC011N03LSI
VISHAY, Si7234DP
VISHAY, CRCW0603124KFKEA
VISHAY, CRCW0603374KFKEA
VISHAY, WSL25122L500FEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW060351K0FKEA
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW060310R0FKEA
VISHAY, CRCW060324K9FKEA
VISHAY, CRCW0603432KFKEA
VISHAY, CRCW06033K01FKEA
VISHAY, CRCW06032K00FKEA
LINEAR TECH., LT3743EUFD#PBF
VISHAY, CRCW06030000Z0EA
MILL MAX 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
KEYSTONE, 8833(SNAP ON)
