3.2 Installing and removing from DIN rail
The IXrouter3 can be easily installed on a standard DIN rail. (1) Hang the device on the rail and
(2) push the unit down until you feel a click. To remove the unit, (A) pull/rotate the device up and
(B) lift off the rail.
Figure 4: DIN-rail installation
3.3 Installing a SIM card
The SIM card slot suits a Full-Size SIM card (size 2FF).
To insert, push the SIM card into the slot until you feel a click. This
is approximately when the card is fully submerged 1 mm inside the
device. Release the card and the card will stay in the device. The
side of the SIM card where you see a golden colored chip should be
aligned with the outside of the enclosure as depicted on the router
and in the figure on the right.
To remove, push the SIM card firmly into the slot until you hear a click. Releasing will cause the
SIM card to partially eject, allowing you to easily take out the card.
