- Page 1 IXrouter3 Installation manual Version 3.1 (Nov. 2020) ...
-
Page 2: Table Of Contents
3.4 Power supply 11 3.5 Wiring 11 4. Operation 12 4.1 Configure the IXrouter3 12 4.2 The IXrouter3 local web interface 12 4.3 LED status indicators 13 4.4 Reset to factory default 14 5. Connectivity requirements (for local IT) 15 ... -
Page 3: Introduction
) , send us an e-mail (support@ixon.cloud), or give us a call at +31 85 744 11 05. Our technical support is available from 8:00 to 17:00 Central European Time, on working days and will answer your questions as ... -
Page 4: Product Overview
2. Product overview Seamlessly integrated with the IXON Cloud, the IXrouter is the fastest and safest way to connect your machine to the cloud. 2.1 Product family The IXrouter3 is available in several variations. No matter your situation, you can always connect ... -
Page 5: Hardware Overview
The IXrouter3 is created with performance and a multitude of hardware capabilities in mind. Figure one, depicted below gives an overview of the hardware functionalities of the IXrouter3. Figure two gives an example of the label that is on the left side of the IXrouter3. Figure 1: Hardware overview ... - Page 6 (s/n). A QR-code with the routers serial number is also provided on the label. On the left side you can find IXON’s contact information and the MAC and IMEI numbers, that are unique to your router. A password (PW) to access the local web interface is also in the left side of the label. ...
-
Page 7: Specifications
2.4 Specifications The specifications below are applicable for all IXrouter3 variants. The 4G, and Wi-Fi variants each have additional specifications, listed separately. Description General specifications Power supply (recommended) 12-24 VDC +/- 20% LPS 2A Power consumption IX2400: 2.5W idle, 10W max ... - Page 8 2FF (Standard SIM Card) FCC ID XMR201903EG25G Wi-Fi specifications Description Wi-Fi IEEE 802.11 version b/g/n Radio Frequency 2.4 GHz Wi-Fi modes Station (Client) Mode and Access Point Speed 72Mbps FCC ID XPYLILYW1 www.ixon.cloud 7 ...
-
Page 9: Dimensions
2.5 Dimensions The IXrouter3 is designed to be easily installed on a standard DIN rail. The small size of the IXrouter3 allows you to make efficient use of space. (Unit of measurement: millimeter.) Figure 3: IXrouter 3 dimensions ... -
Page 10: Installation
You can, for example, access, program and control industrial machines around the globe. Do not use the IXrouter3 unless you’ve received proper training or have proper knowledge about the IXrouter3 and its capabilities. It is expected that the user is knowledgeable ... -
Page 11: Installing And Removing From Din Rail
3.2 Installing and removing from DIN rail The IXrouter3 can be easily installed on a standard DIN rail. (1) Hang the device on the rail and (2) push the unit down until you feel a click. To remove the unit, (A) pull/rotate the device up and ... -
Page 12: Power Supply
Min ground conductor AWG By default, the Digital Input is not configured and doesn't need to be wired. The digital input provides a way to locally manage IXrouter3's VPN connection (ON/OFF). The wiring is depicted in the image above. Type ... -
Page 13: Operation
4.2 The IXrouter3 local web interface You can use the IXrouter3’s local web interface to register the router if it’s not registered in the IXON Cloud, change the WAN, LAN and Firewall configurations locally or use the status overview ... -
Page 14: Led Status Indicators
Removed from the platform (re-insert USB flash drive to register again) Blinking red 5 pulses Previously registered to the IXON Cloud (remove from the IXON Cloud and register again) Blinking blue 1 pulse Connecting to the IXON Cloud Blinking blue 2 pulse ... -
Page 15: Reset To Factory Default
4.4 Reset to factory default When you want to reset the IXrouter3 to factory default, you first need to remove the device from your company in the fleet manager app of the IXON Cloud. The IXrouter3 itself can be reset to ... -
Page 16: Connectivity Requirements (For Local It)
5. Connectivity requirements (for local IT) The IXrouter uses outgoing ports to establish a secure connection to our IXON Cloud. This means there is no need to open any incoming ports in your firewall. 5.1 Overview Below is an overview of the outgoing ports and protocols that the IXrouter utilizes. ... -
Page 17: Compliance
NBTC Verizon ( 4G Global only) ● 6.2 Applicable European directives The IXrouter3 is in conformity with the provisions of the following European Directives. Directive Description EMC Directive 2014/30/EU Product safety Radio Equipment Directive 2014/53/EU Use of the radio spectrum ... - Page 18 UL 60950-1 Information Technology Equipment Safety, Part 1: General Requirements - Edition 2 CSA C22.2 No. 60950-1-07 + Information Technology Equipment Safety, Part Amendment 1 and Amendment 2 1: General Requirements - Edition 2 www.ixon.cloud 17 ...
-
Page 19: Fcc Compliance
Changes or modifications of this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. The IXrouter3 contains different FCC certified modules, depending on the variant. Article no. Enclosed module ... -
Page 20: Anatel
ใช ้ เ ครื ่ อ งวิ ท ยุ ค มนาคมที ่ ค ณะกรรมการกิ จ การโทรคมนาคมแห ่ ง ชาติ ป ระกาศก าหนด. Drawings and official documents All supporting documents can be found on our support website. Click here for more info. www.ixon.cloud 19 ...
