TFP680
Page 16 of 16
Standard Response (SR)
570 TY-B 5.6K Upright SR
590 TY-B 8.0K Upright SR
571 TY-B 5.6K Pendent SR
591 TY-B 8.0K Pendent SR
573 TY-B 5.6K C/UP SR
593 TY-B 8.0K C/UP SR
578 TY-B 5.6K HSW SR
575 TY-B 5.6K VSW SR
SERIES TY-B AND TY-FRB SPRINKLERS ALTERNATE MATERIALS OF CONSTRUCTION
Care and
Maintenance
The TYCO Series TY-B and TY-FRB
Sprinklers must be maintained and ser-
viced in accordance with this section.
Before closing a fire protection system
main control valve for maintenance
work on the fire protection system that
it controls, permission to shut down the
affected fire protection system must be
obtained from the proper authorities
and all personnel who may be affected
by this action must be notified.
The owner must assure that the sprin-
klers are not used for hanging of any
objects; otherwise, non-operation in
the event of a fire or inadvertent oper-
ation may result.
Absence of an escutcheon, which is
used to cover a clearance hole, may
delay the time to sprinkler operation in
a fire situation.
Sprinklers that are found to be leaking
or exhibiting visible signs of corrosion
must be replaced.
Automatic sprinklers must never be
painted, plated, coated or other-
wise altered after leaving the factory.
Modified sprinklers must be replaced.
Sprinklers that have been exposed to
corrosive products of combustion, but
have not operated, should be replaced
if they cannot be completely cleaned
by wiping the sprinkler with a cloth or
by brushing it with a soft bristle brush.
1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone +1-215-362-0700
© 2020 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
NATIONAL FIRE PROTECTION ASSOCIATION and NFPA are registered trademarks of National Fire Protection Association
TEFLON is a registered trademark of DuPont
254 SMO is a trademark of Avesta Sheffield
P/N 57 — XXX — 0 — XXX — SUFFIX
Quick Response (QR)
370 TY-FRB 5.6K Upright QR
390 TY-FRB 8.0K Upright QR
371 TY-FRB 5.6K Pendent QR
391 TY-FRB 8.0K Pendent QR
373 TY-FRB 5.6K C/UP QR
393 TY-FRB 8.0K C/UP QR
378 TY-FRB 5.6K HSW QR
375 TY-FRB 5.6K VSW QR
TABLE E
PART NUMBER SELECTION
Care must be exercised to avoid
damage to the sprinklers before,
during, and after installation. Sprin-
klers damaged by dropping, striking,
wrench twist/slippage, or the like, must
be replaced. Also, replace any sprinkler
that has a cracked bulb or that has lost
liquid from its bulb. See the Installation
Section for more information.
Frequent visual inspections are rec-
ommended to be initially performed
for corrosion resistant sprinklers, after
the installation has been completed,
to verify the integrity of the corrosion
resistant material of construction.
Thereafter, annual inspections per
NFPA 25 should suffice; however,
instead of inspecting from the floor
level, a random sampling of close-up
visual inspections should be made, so
as to better determine the exact sprin-
kler condition and the long term integ-
rity of the corrosion resistant material
of construction, as it may be affected
by the corrosive conditions present.
The owner is responsible for the
inspection, testing, and maintenance of
their fire protection system and devices
in compliance with this document, as
well as with the applicable standards
of the NFPA (for example, NFPA 25), in
addition to the standards of any other
authorities having jurisdiction. Contact
the installing contractor or product
manufacturer with any questions.
Automatic sprinkler systems should be
inspected, tested, and maintained by a
qualified Inspection Service in accor-
dance with local requirements and/or
national codes.
Temperature Rating
135 135°F (57°C)
155 155°F (68°C)
175 175°F (79°C)
200 200°F (93°C)
286 286°F (141°C)
360 360°F (182°C)*
* TY-B only
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
Contact your local distributor for
availability. When placing an order,
indicate the full product name and Part
Number (P/N).
Contact your local distributor for avail-
ability. When placing an order, indicate
the full product name and Part Number
(P/N).
Sprinkler Assemblies with NPT
Thread Connections
Specify: (specify SIN), (specify Stan-
dard Response or Quick Response),
(specify K-factor), (specify) tempera-
ture rating, (specify Pendent Upright,
C/UP, HSW, or VSW) Sprinkler with
(specify type material: Stainless Steel,
SMO, or Titanium), P/N (specify from
Table E)
Recessed Escutcheon
Specify: Style (10 or 40) Recessed
Escutcheon with (specify material or
finish*), P/N (specify)
*See Technical Data Sheet TFP770.
Sprinkler Wrench
Specify: W-Type 6 Sprinkler Wrench,
P/N 56-000-6-387
Specify: W-Type 7 Sprinkler Wrench,
P/N 56-850-4-001
Material
None Stainless Steel
M SMO**
T Titanium**
** 5.6K only
