Components:
*
- Frame
1
- Button
2
3 - Sealing
Assembly
4 -
Bulb
-
5 Compression
Screw
*
6 -
De ector
7 - Ejection
Spring
1-13/16"
(46,0 mm)
*
Temperature
rating is indicated
on de ector or
adjacent to ori ce
seat on frame.
**
Pipe thread
connections per
ISO 7-1 can be
provided on
special request.
SERIES TY-B HORIZONTAL SIDEWALL STANDARD RESPONSE SPRINKLER
STAINLESS STEEL (TY8391), SMO (TY8392) AND TITANIUM (TY8393)
DEFLECTOR
HAT
*
6
9/16"
7
(14,3 mm)
7/16"
(11,1 mm)
NOMINAL
CENTERLINE
MAKE-IN
OF SPRINKLER
WATERWAY
1-1/2"
(38,1 mm)
STYLE 10
RECESSED
ESCUTCHEON
2-7/8" DIA.
(73,0 mm)
FIGURE 9
5.6 K-FACTOR, 1/2 IN. NPT
5
*
4 2 3 1
**
WRENCH
1/2"
FLATS
NPT
2-1/4"
(57,2 mm)
ESCUTCHEON
PLATE SEATING
SURFACE
TFP680
