EcoQuest Fresh Air Spectrum UVX Quick Start Manual

Operation
If your Fresh Air Spectrum UVX
with an international AC adapter, you will need to
select and install the proper plug (see below) .
Plug the adapter into a working receptacle and into
the back of the unit. Set the unit upright on a stable,
flat surface.
Fresh Air Spectrum UVX
adapters are controlled by a single on/off switch
located on the electrical cord. Units equipped with
international adapters do not have a switch.
ABOUT THE INTERNATIONAL PLUG ADAPTER:
When installing one of the interchangeable plugs, be sure to snap
and lock the plug into the adapter. When removing a plug, press
the raised tab to release, then slide the plug out the top.
PRESS HERE
WARNING! - UV Lamp operation. Do not operate unless the unit is completely
and correctly assembled. Failure to comply may result in serious eye damage.
RCI Cell Replacement
™
If the unit no longer produces light
or the light has become dim (after
approx. 25,000 hrs of operation), the
RCI Cell should be replaced.
™
Contact your EcoQuest Dealer for
more information on a replacement
RCI Cell.
™
3
Lift the RCI shield
™
up about 1/4" to
release it from the
upper tab.
Note: The AC transformer may feel warm to the touch.
Over time some discoloration of the clear panel may occur.
has been equipped
™
™ units with standard AC
1
Remove the two
screws located at the
back of the unit.
4
Lay the RCI shield
™
over and remove the
RCI cell from the
™
retaining clips.
SPECIFICATIONS
• 12VDC
• 11 watts power consumption
• Advanced Oxidation: 0.01 ppm
• Size: 6" x 12" x 3"
(15cm x 30cm x 7cm)
• Weight: 2 pounds (.9kg)
• Coverage: up to 500 ft
• One Year limited warranty
- see warranty card for details
Hg - LAMP CONTAINS MERCURY.
Manage in accordance with local laws.
See www.lamprecycle.org.
CAUTION! - Disconnect power cord before servicing.
2
Tilt the bottom of the
RCI shield away
™
from the unit.
5
Remove the RCI
™
cell from the plug.
Replace with new
RCI cell.
™
6
Reverse steps 1 - 4 to reassemble.
(46m )
2 2
