CleverLevel
Point level detection – hygienic/industrial
3. Symbols in warning signs
Symbol Warning term
DANGER
WARNING
CAUTION
ATTENTION
4.

Transport and storage

Check packaging and sensor for damage.
f „
In the event of damage: Do not use sensor.
f „
5. Assembly
1
4
Fig. 3. Mounting options
4 / 33
Level measurement
® LBFH/I
Explanation
In situations which cause death or serious injuries.
In situations which can cause death or serious injuries.
In situations which can cause light or medium injuries.
For material damage
2
3
4
4
Operating Instructions
Store sensor where it will be secure against
f „
shock.
Storage temperature: -40 ... +85 °C
Relative humidity: < 98 %
1 Overfill protection
2 Limit level, max.
3 Limit level, min.
4 Run-dry protection
The sensor can be mounted on any point in the
vessel.
A sensor mounted at the top of the vessel (1)
ensures against overfilling. Sensors attached
further down detect a maximum (2) or minimum (3)
limit level. A sensor attached at the bottom or on
the outfeed pipe (4) can protect a connected pump
against dry running.
